Menu 6.2 – Courtesy Light Output Mode
The relay output in the courtesy mode can be adjusted from 30 seconds to 18 hours. This sets the time
the courtesy light is activated. Factory default is 1 minute.
Menu No. Courtesy Light Mode
6.2.1 Courtesy Light Activation
6.2.2
Menu 6.3 – Strobe (Warning) Light Output Mode
The relay output in the strobe (Warning) mode can be configured in different ways:
Menu No. Strobe (Warning) Light Mode
Pre-Open Strobe (Warning)
6.3.1
Pre-Close Strobe (Warning)
6.3.2
6.3.3

6.3.1 Pre-Open Strobe Light Activation

This sets the time the strobe light is activated before the gate/door operates in the open direction.
Factory default is Off.

6.3.2 Pre-Close Strobe Light Activation

This sets the time the strobe light is activated before the gate/door operates in the close direction.
Factory default is Off.
20
Exit
Light Activation
Light Activation
Exit
Factory
Default
1 minute
Factory
Default
Off
Off
Gate & Door Controller with Eclipse
Adjustable
30 seconds to
18 hours
Adjustable
0 – 30 seconds
0 – 30 seconds
Operating System (EOS)
®
