7.4 Automatic Stop / Open on Closing

By default if the gates/doors is closing and a push button or remote control is activated it will automatically
stop and open the gates/doors. When this feature is disabled then the gates/doors will stop on an
activation of the push button or remote control.

7.5 Receiver Channel 2 Options

The receivers 2nd channel can be programmed to control a courtesy light or can be used as pedestrian
access.
7.6 & 7.7 Press and Hold for Open and Close Inputs
If this feature is ON the user must continuously press the open or close input for it to be activated.
7.8 Window or Louvre Mode
This mode optimises the control card for operating electronic windows or louvres.
Menu 8 – Leaf Delay
Leaf delay is used when one gate leaf will close in an overlapping position to the first closed leaf. This
leaf delay may also be necessary for special add-on locking pins. The control card has separate leaf
delay for the open and close directions.
When the control card is used with a single motor the leaf delay mode is disabled.
Menu No.
8.1
8.2

Close Leaf Delay

8.3

8.1 Open Leaf Delay

Motor 1 will start opening first. After leaf delay time has expired motor 2 will start opening.
8.2 Close Leaf Delay
Motor 2 will start closing first. After leaf delay time has expired motor 1 will start closing.
8.3 Close Leaf Delay on Mid Stop
By default motor 1 will always have delay when closing even if the gate is not fully open. When disabled
both motor 1 and motor 2 will start closing at the same time only when not fully open.
www.elsema.com
Leaf Delay
Open Leaf Delay
Exit
Factory
Default
3 seconds Off - 25 seconds
3 seconds Off - 25 seconds
Adjustable
