Menu 6.4 – Service Call Output Mode
This sets the number of complete cycles (Open and Close) required before the built-in buzzer is
activated. Also the control card outputs can be configured to be activated if the number of cycles is
completed. Connecting Elsema's GSM-1000 alert receiver to the output allows owners to get a phone
call or SMS message when the service is due.
When "Service Call Due" message shows up on the LCD a service call is required. After service has
been done, follow the messages on the LCD.
Menu No. Service Call Mode
6.4.1
6.4.2
Menu 6.5 – Locking Actuator Output Mode
The time for which relay output 1 turns "on" before the gate/door starts to open and the time for which
relay 2 turns "on" after the gate/door is fully closed can be adjusted as below:
Menu No. Locking Actuator
6.5.1 Pre-Open Lock Activation
6.5.2 Post-Close Lock Activation
6.5.3
6.5.1 Pre-Open Locking Actuator Activation
This sets the time relay 1 is activated before the gate/door operates in the open direction. Factory default
is Off.
6.5.2 Post-Close Locking Actuator Activation
This sets the time relay 2 is activated after the gate/door is fully closed. Factory default is Off.
www.elsema.com
Service Counter
Exit
Exit
Factory
Default
Off Min: 2000 to Max: 50,000
Factory
Default
Off 0 – 30 seconds
Off 0 – 30 seconds
Adjustable
Adjustable
