Menu 6.2 – Courtesy Light Output Mode
The relay output in the courtesy mode can be adjusted from 2 seconds to 18 hours. This sets the time
the courtesy light is activated. Factory default is 1 minute.
Menu No. Courtesy Light Mode
6.2.1 Courtesy Light Activation
Courtesy Light at Night Only with
6.2.2
6.2.3
Menu 6.3 – Strobe (Warning) Light Output Mode
The relay output in the strobe (Warning) mode can be configured in different ways:
Menu No. Strobe (Warning) Light Mode
Pre-Open Strobe (Warning)
6.3.1
Pre-Close Strobe (Warning)
6.3.2
6.3.3

6.3.1 Pre-Open Strobe Light Activation

This sets the time the strobe light is activated before the gate/door operates in the open direction.
Factory default is Off.

6.3.2 Pre-Close Strobe Light Activation

This sets the time the strobe light is activated before the gate/door operates in the close direction.
Factory default is Off.
20
LDR Connected
Exit
Light Activation
Light Activation
Exit
Double Gate & Door Controller
Factory
Default
1 minute
Off
Factory
Default
Off 0 – 30 seconds
Off 0 – 30 seconds
with Eclipse
Adjustable
2 seconds to
18 hours
Off/On
Adjustable
Operating System (EOS)
®
