1.2General Specifications
General
Dimensions(WxHxD): 218x151x74.2 mm (8.58"X5.94"X2.92 ")
Weight:1.8 kg (6.6 Ibs)
Power supply: ATX type
Input Voltage:
Output Voltage: 5V@5A, 12V@1A
Power adaptor AC/DC
Input Voltage: 100~240V ac
Output Voltage:19V@3.16A
Disc Driver housing: Space for one 2.5"HDD.
Front Panel: IP65/NEMA compliant.
Standard PC functions
CPU: Onboard VIA Eden™ 400 MHz processor
BIOS: Award 256 KB Flash BIOS.
System Chipset: VIA PN 133T Chipset
Front Side bus:133 MHz
2nd level cache: 64 KB on the Eden processor.
System Memory: One 144-pin SODIMM socket up to 512
MB SDRAM
Series ports: Two serial ports with two-232 ports, one is
RS232 ports; the other is RS-232/422/485 port. All ports are
compatible with 16C550UARTs, +5V/+12V power supply
selectable.
Universal serial bus (USB port: Support up to one USB port
and Intel UHC1v1.1 compatible.
SSD: Built in Type 1 Compact Flash socket, supports
Compact Flash card shared with one IDE channel.
Watchdog timer: 62-level, internal 1~62 seconds.
Automatically generates system reset or IRQ11 when the
system stops due to a program error or EMI. Jumperless
12V
-24 V
3.5A max.
dc
dc,
