Chapter 3 Jumper Setting and Connectors.

3.1 Jumpers
The motherboard of the PPC-L60T has a number of jumpers that
allow you to configure your system to suit your application. The
table below lists the functions of the various jumpers.
Table 3.1: Jumpers
Label
S1 Panel type select
S2 CMOS clear button
S3 System reset button
JP1 COM2 RS232/422/485 & WDT setting
3.2 Connectors
On-board connectors link the PPC-L60T to external devices
such as hard disk drives, a keyboard, or floppy drives. The
table below lists the func- tion of each of the board's
connectors.
Table 3.2: Connectors
Label
CN1 ATX feature
CN2 CPU fan power
CN3 Ext. flat panel
CN4 Flat panel connector
CN5 LCD Inverter control connector
CN6 LVDS connector
CN7 Main Power connector
CN8 ATX power on/off switch connector
CN9 Peripheral power connector (-5V, -12V)
Function
Function
