3. To change the roller at the top:
4. Insert the new roller into its
48
ArtixScan DI 6240S/6250S/6260S & ArtixScan TS 630S User's Manual
a)
Rotate the lever on the roller shaft
down to loosen the roller.
b)
Move the roller shaft to the left
horizontally.
c)
Hold the both sides of the roller to
pull it out carefully from its
compartment.
compartment:
a)
Mount the roller with a white cap at
the right of the roller into the
mounting socket at the right side of
the compartment.
b)
Then, move the roller shaft to the
right horizontally. Insert it into a
hollow at the left side of the roller
until it sticks into place.
c)
Rotate the lever on the roller shaft
up to fasten the roller, and push the
whole assembly back into its
compartment.
Lever
Roller shaft
