Start Here
Installing your Microtek ArtixScan DI 4020 Plus / ArtixScan DI 2020 Plus
Step 1:
Unpack your scanner package and check
for major components.
1. Document scanner
2. Power adapter
3. Power cord
4. Software CDs/DVDs
5. Hi-Speed USB cable
Step 2:
Important: Do not remove the yellow stickers from
your scanner until you are told to do so. You must
install software before connecting your scanner.
Always close any open programs and turn off Anti-
virus utilities before installing software.
A. Turn on your computer.
B. Place the Microtek Software CD/DVD into a drive, and follow the on-screen
instructions to install the scanner driver and software.
C. Restart your computer at the end of all software installation.
NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the
following in succession: "My Computer"; the CD/DVD-ROM icon; then cdsetup.exe to start the
installer program.
Copyright © 2013 Microtek International, Inc. http://www.microtek.com
I49-004804 B, September 2013
Unpack Contents
Install Software
1
5
4
1
2
3
Advertisement
Related Manuals for Microtek ArtixScanDI 4020 Plus
Summary of Contents for Microtek ArtixScanDI 4020 Plus
- Page 1 C. Restart your computer at the end of all software installation. NOTE: If the Microtek Software Installer screen does not come up automatically, double-click the following in succession: “My Computer”; the CD/DVD-ROM icon; then cdsetup.exe to start the installer program.
-
Page 2: Unlock Scanner
Unlock Scanner A. Remove the yellow “Step 3” sticker from your scanner. B. With the scanner power off, tilt the scanner and locate the locking switch at the bottom left corner of the scanner. Do not turn the scanner upside down when attempting to unlock, as this may damage the scanner’s mechanism. - Page 3 Step 4: Connect Scanner (cont.) To the Hi-Speed USB cable D. Connect one end of the Hi-Speed USB cable to your computer. E. Connect the other end of the Hi-Speed USB cable to the scanner’s USB port. F. Press the Power button at the front panel of your scanner to turn on the scanner;...
- Page 4 Document Feed Tray. WARNING: The document feeder is not designed for scanning photos; doing so may damage your originals. Microtek accepts no responsibility for damage that may arise from misuse of equipment. Guide Arms 3.
- Page 5 Scan a Stack of Documents 1. Place the stack of documents to be scanned on the Document Feed Tray of the Auto Document Feeder (ADF). WARNING: Do not place photo paper or fragile sheets of paper on the feed tray, as doing this will damage the original photo or frail papers during the feeding process.
- Page 6 Scan a Stack of Documents (cont.) 6. Click the Scan button, or click the Custom Scan button and select “Save to File” to start multiple-sheet, automatic scanning. NOTE: When you finish loading documents on the Document Feed Tray, the documents remain on the tray. When scanning is initiated, the stack of papers is moved automatically from the Automatic Moving Tray in preparation of the scanning process.
-
Page 7: Fixing Paper Jams
Fixing Paper Jams Open the ADF cover by pressing the button • If a paper jam has occurred in the on the top of the ADF. rollers under the ADF cover, pull out the paper by using a forward-moving direction. ADF cover Button Paper jams can occur in either of two... - Page 8 Problems? The LEDs on the button panel indicates the status of the scanner. On - Ready to scan Flashing Green - Scanning Off - Scanner is off LEDs First, make sure that you have followed Steps 1 to 4 as described in this document (unpack, install, unlock, connect).
- Page 9 Finally, select and click the title of the manual you wish to view. Missing Items If your package is missing items, please call the Microtek Customer Service Department. Drivers & Software Upgrades After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download...
