Scanning Documents with Barcodes

This scanning scenario is useful for the documents to be filed with barcode
numbers.
1. Load the documents to be scanned onto the scanner's document feed tray.
2. Launch ScanWizard DI as a stand-alone program by clicking on the
ScanWizard DI icon on the desktop.
3. Click the Scan Setup button in the interface to activate the Scan Setup
interface.
4. Follow the procedure (steps 4 through 7) for "Scanning Documents" section
to specify your scanning requirements in the interface.
5. Click the OK button to close the Scan Setup interface and return to the Main
interface of ScanWizard DI.
6. In the Main interface, click the File Format menu button to select a file format
for the scanned images.
7. In the Main interface, click the File Name
menu button and then select
"Barcode+Suffix" from its drop-down menu
for the scanned images.
NOTE: If you want to know more about how
to deal with documents with barcodes, refer
to the ScanWizard DI Reference Manual in the
Microtek Software CD/DVD.
8. In the Main interface, select and click the Normal Scan button to start
scanning.
When done, the scanned images will be automatically saved into the folder
defined in the File Location menu box. At the same time, the scanned images
will be displayed in thumbnail sizes in the Thumbnail View window and
labeled with detected barcode values and chosen file format.
9. Click the Open Folder button to locate the scanned images if you want to
view.
ArtixScan DI 6240S/6250S/6260S & ArtixScan TS 630S User's Manual 29
