S Y S T E M M E N U
MENU
FUNCTION
MODE
Button
Preset
Volume
DMX Address
DMX
MODE
DMX mode
Duration
Interval
UP/DOWN
Button
65°C, 70°C, Select the desired preset water temperature
75°C or 80°C (65°C, 70°C, 75°C or 80°C)
10%-100% Select the desired output volume (10% - 100%)
1 - 512 Sets the DMX starting address (001-512)
1ch The unit occupies 1 DMX channels
2ch The unit occupies 2 DMX channels
6ch The unit occupies 6 DMX channels
10 s – 250 s Set the duration of timed fogging (10-250 seconds)
10 s – 250 s Set the interval of timed fogging (10-250 seconds)
13
