O V E R V I E W
INCLUDED ITEMS:
(1) Entour Ice
(1) Flight Case Cover
(1) Fog Conduction Hose 5' (1.5M)
B
A
F
P Q R S
A. Carry Handle
B. Cooler Box
C. Fog Outlet
D. Fog Conduction Hose 5' (1.5M)
E. Water Tank
F. Wheels
G. Flight Case Cover
H. Dry Ice Basket
I. LCD Display and Function Buttons
J. Water Level Indicator
K. Drain Valve
E
O
T U V W
C
D
N
L. Smoke On/Off Button
M. LED Indicator
N. Upper Cover Lock
O. Power Input LED Indicator
P. Main Power Input
Q. No Fuse Breaker (NFB)
R. Auxiliary Power Input
S. No Fuse Breaker (NFB)
T. DMX 3 Pin XLR Input
U. DMX 3 Pin XLR Output
V. DMX 5 Pin XLR Input
W. DMX 5 Pin XLR Output
9
G
H
K
M
L
I
J
