ADJ ENTOUR ICE User Manual page 16

O P E R A T I O N ( W I T H D M X )
See page 17 for each mode's DMX traits.
DMX Addressing and Channel Mode: This function will allow you to control each individual
fixture's traits with a standard DMX 512 controller. When the Entour Ice detects a DMX signal, it
will enter DMX Mode automatically (with the exception of Manual Mode).
Press the FUNCTION button to enter DMX mode setting.
Press UP/DOWN to select the channel mode (1ch, 2ch or 6ch.)
DMX Address
• Press FUNCTION button to enter the DMX address setting
• Press UP/DOWN to adjust the DMX address
• When the desired DMX value is set, the DMX address will automatically be saved.
During DMX Operation, the DMX Channel mode can still be switched between 1ch, 2ch and
6ch by pressing the FUNCTION button.
• The DMX Channel can also be adjusted using the UP/DOWN button during DMX
Operation.
DMX CHANNEL MODE DISPLAY
1ch Mode:
1ch Addr1 72°C
Smoke OFF 100%
2ch Mode:
2ch Addr1 72°C
Smoke OFF 100%
6ch Mode:
6ch Addr1 72°C
Dur.xxx Int.xxx
OFF 10% 72°C
Dur.xxx Int.xxx
OFF 10% X
Dur.xxx Int.xxx
The first line shows the 1ch mode, the DMX address and the
current water temperature; the second line shows the current
status of smoking ON/OFF, and output volume controlled by DMX
console. Please note that the default smoke output is 100% when
in 1ch mode and it is not adjustable.
The first line shows the 2ch mode, the DMX address and the
current water temperature. The second line shows the current
smoke output ON/OFF, and output volume controlled by DMX
console.
The first line shows the 6ch mode, the DMX address and the
current water temperature. The second line shows the current
duration and interval setting by DMX console.
After 2 seconds, the screen will switch into working status and
display the current status of smoke ON/OFF, and output volume
and current water temperature. The second line shows the current
duration and interval setting by DMX console. If the water
temperature is between 0-31, heating will stop and the
temperature will be shown as "X".
