Dmx Channels / Values / Functions - ADJ ENTOUR ICE User Manual

D M X C H A N N E L S / V A L U E S / F U N C T I O N S
DMX CHANNELS / VALUES / FUNCTIONS (3 Modes 6 Channels)
MODE (1,2 and 6) / CHANNEL
1ch
1
SUPPORTS SOFTWARE VERSION 1.0
2ch 6ch
1 1
2 2
3
4
5
6
VALUE
Smoke ON/OFF
0 - 31 Off
32 - 255 ON
Volume
0 - 28 10%
29 - 255 11-100%
Duration
0 - 10 10 Seconds
11 - 249 11-249 Seconds
250 - 255 250 Seconds
Interval
0 - 4 0 Seconds
5 - 10 10 Seconds
11 - 249 11-249 Seconds
250 - 255 250 Seconds
Preset Temperature
0 - 63 65°C
64 - 127 70°C
128 - 191 75°C
192 - 255 80°C
Heater
0 - 31 Off
32 - 255 On
17
FUNCTION
