Anybus Configuration Manager

4 Anybus Configuration Manager
4.1

Introduction

The Anybus X-gateway usually requires only a minimum of configuration during setup, since the
on-board network interfaces are configured from the respective networks. Some parameters in
the gateway may however need to be adjusted to suit specific networks and applications.
The gateway settings are accessed via the USB port of the X-gateway using the Windows-based
application Anybus Configuration Manager.
This section describes only the general features and how to install Anybus Configuration Manager.
The network-specific settings are described in detail in the built-in help system and in the
documentation for each respective interface.
Anybus Configuration Manager requires Windows XP or later.
Fig. 8 Anybus Configuration Manager
