Connectors and Indicators

Fig. 7 Connectors
3.2.1 Power Connector (X3)
Pin
1
2
3.2.2 USB Connector (X4)
Pin
1
2
3
4
Housing
3.2.3 LED Indicators
LED
GW Status
Other LED indicators, connectors and configuration switches are described in the documentation
for each respective network interface.
Anybus ® X-gateway ™ User Manual
Connecting power with reverse polarity or using the wrong type of power supply may
damage the equipment. Make sure that the power supply is connected correctly and of
the recommended type.
Signal
+24 VDC
Power Ground
Signal
+5 V input
USBDM (USB communication)
USBDP (USB communication)
Signal ground
Cable shield
Indication
Green
Red
Red, flashing
Meaning
Communication running
Communication error
Network interface error
