Chapter 3: Jumpers and Switches
Internal Connectors
SATA Connectors (7-pin and 15-pin)
Connector type: Standard Serial ATA 7P and 15P
Connector location: SATA1 & SATA2
P15
Pin
Definition
S1
GND
S3
SATA_TXN
S5
SATA_RXN
S7
GND
P2
NC
P4
GND
P6
GND
P8
VCC5
P10
GND
P12
GND
P14
NC
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
S1
Pin
Definition
S2
SATA_TXP
S4
GND
S6
SATA_RXP
P1
NC
P3
NC
P5
GND
P7
VCC5
P9
VCC5
P11
NC
P13
NC
P15
NC
39
