Specifications

9.7.5 Figure 5 - 914CBR-VxxxCT

[39,37]
1000
9 9
1 Name plate
2 Hot surface warning x2
Illustration 9.24 IP54, Side View and Top View
Resistor cable
Temperature switch
Table 9.10 Cable Details
Danfoss P/N
175U3301
175U3302
175U3303
175U3304
175U3310
175U3311
175U3312
175U3313
175U3317
175U3318
175U3319
175U3320
175U3321
175U3326
175U3327
175U3328
175U3329
175U3335
96
Design Guide
1
+1,97
0,00
+50
0
AWG 16, UL Style 1659, 600 V, 250 °C
180 °C NC, AWG 20, orange
Typecode
MCE101A100RP450RE54CAW
MCE101A70R0P570RE54CAW
MCE101A48R0P960RE54CAW
MCE101A35R0P1K13E54CAW
MCE101A410RP450RE54CAW
MCE101A270RP570RE54CAW
MCE101A200RP960RE54CAW
MCE101A145RP1K13E54CAW
MCE101A850RP280RE54CAW
MCE101A570RP450RE54CAW
MCE101A415RP570RE54CAW
MCE101A270RP960RE54CAW
MCE101A200RP1K13E54CAW
MCE101A27R0P360RE54CAW
MCE101A18R0P570RE54CAW
MCE101A13R0P680RE54CAW
MCE101A9R00P1K13E54CAW
MCE101A110RP450RE54CAW
Danfoss A/S © Rev. 05/2014 All rights reserved.
L
L1
2
[Ω] L ±2 mm L ±0.08 in
100 260 10.24
70 330 12.99
48 560 22.05
35 660 25.98
410 260 10.24
270 330 12.99
200 560 22.05
145 660 25.98
850 160 6.30
570 260 10.24
415 330 12.99
270 560 22.05
200 660 25.98
27 210 8.27
18 330 12.99
13 400 15.75
9 660 25.98
110 260 10.24
[0,71]
18
L1 ±2 mm L1 ±0.08 in
Weight [kg]
160 6.3
230 9.06
460 18.11
560 22.05
160 6.30
230 9.06
460 18.11
560 22.05
70 2.76
160 6.30
230 9.06
460 18.11
560 22.05
110 4.33
230 9.06
300 11.81
560 22.05
160 6.30
2.4
3
4.6
5.4
2.4
3
4.6
5.4
1.3
2.4
3
4.6
5.4
1.8
3
3.5
5.4
2.4
MG90O202
