Selection Guide
8.2.8 VLT ®
Decentral Drive FCD 302
10% duty cycle, horizontal braking, T4
FCD 302
Frequency converter data
R R
Mains P
min br,nom
m
type [kW] [Ω] [Ω]
T4 0.37 1000
T4 0.55 620
T4 0.75 558
T4 1.1 382
T4 1.5 260
T4 2.2 189
T4 3 135
Table 8.33 T4, Horizontal Braking 10% Duty Cycle
40% duty cycle, vertical braking, T4
FCD 302
Frequency converter data
R R
Mains P
min br,nom
m
type [kW] [Ω] [Ω]
T4 0.37 1000
T4 0.55 620
T4 0.75 558
T4 1.1 382
T4 1.5 260
T4 2.2 189
T4 3 135
Table 8.34 T4, Vertical Braking 40% Duty Cycle
MG90O202
Design Guide
R
P
rec
br,cont.
[Ω] [kW]
1281.6 1200 0.100
856.9 850 0.100
625.8 630 0.100
417.5 410 0.100
300.6 270 0.200
201.7 200 0.200
146.2 145 0.300
R
P
rec
br,cont.
[Ω] [kW]
1281.6 1200 0.200
856.9 850 0.200
625.8 630 0.300
417.5 410 0.450
300.6 270 0.570
201.7 200 0.960
146.2 145 1.130
Danfoss A/S © Rev. 05/2014 All rights reserved.
Horizontal braking 10% duty cycle
Brake resistor data
Danfoss part number
Screw Screw
Wire IP54 terminal terminal
IP21 IP65
175u3000 - -
175u3001 - -
175u3002 - -
175u3004 - -
175u3007 - -
175u3008 - -
175u3300 - -
Vertical braking 40% duty cycle
Brake resistor data
Danfoss part number
Screw Screw
Wire IP54 terminal terminal
IP21 IP65
175u3101 - -
175u3308 - -
175u3309 - -
175u3310 175u3416 175u3415
175u3311 175u3418 175u3417
175u3312 175u3420 175u3419
175u3313 175u3422 175u3421
Installation
Cable
cross-
Bolt Thermo
section
connection relay
IP20 [mm 2 ] [A]
- 1.5 0.3
- 1.5 0.4
- 1.5 0.4
- 1.5 0.5
- 1.5 0.8
- 1.5 0.9
- 1.5 1.3
Installation
Cable
cross-
Bolt Thermo
section
connection relay
IP20 [mm 2 ] [A]
- 1.5 0.4
- 1.5 0.5
- 1.5 0.7
- 1.5 1
- 1.5 1.4
- 1.5 2.1
- 1.5 2.7
