Selection Guide
8.2.4 VLT ®
AQUA Drive FC 202
10% duty cycle, horizontal braking, T2
FC 202
Frequency converter data
R R
Mains P
min br,nom
m
type [kW] [Ω] [Ω]
T2 0.25 380
T2 0.37 380
T2 0.55 275
T2 0.75 188
T2 1.1 130
T2 1.5 81.0
T2 2.2 58.5
T2 3 45.0
T2 3.7 31.5
T2 5.5 22.5
T2 7.5 17.7
T2 11 12.6
T2 15 8.7
T2 18.5 5.3
T2 22 5.1
T2 30 3.2
T2 37 3.0
T2 45 2.4
Table 8.11 T2, Horizontal Braking 10% Duty Cycle
MG90O202
Design Guide
R
P Wire IP54
rec
br,cont.
[Ω] [kW]
691.3 630 0.100
466.7 410 0.100
313.7 300 0.100
230.0 200 0.100
152.9 145 0.100
110.5 100 0.100
74.1 70 0.200
53.7 48 0.200
39.9 35 0.300
28.7 27 0.360
20.8 18 0.570
14.0 13 0.680
10.2 9.0 1.130
8.2 5.7 1.400
6.9 5.7 1.700
5.0 3.5 2.200
4.1 3.5 2.800
3.3 2.8 3.200
Danfoss A/S © Rev. 05/2014 All rights reserved.
Horizontal braking 10% duty cycle
Brake resistor data
Danfoss part number
Screw Screw
terminal terminal
IP21 IP65
175u3002 - -
175u3004 - -
175u3006 - -
175u3011 - -
175u3016 - -
175u3021 - -
175u3026 - -
175u3031 - -
175u3325 - -
175u3326 175u3477 175u3478
175u3327 175u3442 175u3441
175u3328 175u3059 175u3060
175u3329 175u3068 175u3069
175u3330 175u3073 175u3074
175u3331 175u3483 175u3484
175u3332 175u3080 175u3081
175u3333 175u3448 175u3447
175u3334 175u3086 175u3087
Installation
Cable
cross-
Bolt Thermo
section
connection relay
IP20 [mm 2 ] [A]
- 1.5 0.4
- 1.5 0.5
- 1.5 0.6
- 1.5 0.7
- 1.5 0.8
- 1.5 0.9
- 1.5 1.6
- 1.5 1.9
- 1.5 2.7
- 1.5 3.5
- 1.5 5.3
- 1.5 6.8
- 2.5 10.5
- 4 15
- 4 16
- 6 24
- 10 27
- 16 32
8 8
41
