Danfoss VLT Brake Resistor MCE 101 Design Manual page 79

Specifications
Enclosure
Weight
P/N rating
[kg]
[IP class]
175U3160 9.2 21
175U3161 9.2 65
175U3162 44.5 21
175U3163 44.5 65
175U3166 39 21
175U3167 39 65
175U3168 11.0 21
175U3169 11.0 65
175U3170 44.5 21
175U3171 44.5 65
175U3172 14.6 21
175U3173 14.6 65
175U3174 25.5 21
175U3175 26.5 65
175U3176 32.5 21
175U3177 33.5 65
175U3178 32.5 21
175U3179 33.5 65
175U3180 44.5 21
175U3181 44.5 65
175U3182 44.5 21
175U3183 44.5 65
175U3200 22 20
175U3201 25 20
175U3202 35 20
175U3203 20 20
175U3204 25 20
175U3205 41 20
175U3206 25 20
175U3207 35 20
175U3208 41 20
175U3209 45 20
175U3210 35 20
175U3211 45 20
175U3212 74 20
175U3213 41 20
175U3214 78 20
175U3215 90 20
175U3216 45 20
175U3217 74 20
175U3218 90 20
175U3219 74 20
175U3220 182 20
175U3221 78 20
175U3222 190 20
175U3223 90 20
175U3224 25 20
175U3225 90 20
175U3227 35 20
175U3228 182 20
175U3230 190 20
MG90O202
Design Guide
UL Product type
N 914CBT-H460DHT
N 914CBT-H460BHT
N 930CBT-V760GHT
N 930CBT-V760BGHT 930CBT-VxxxBGHT
N 930CBT-V660GHT
N 930CBT-V660BGHT 930CBT-VxxxBGHT
N 914CBT-H560DHT
N 914CBT-H560BHT
N 930CBT-V760GHT
N 930CBT-V760BGHT 930CBT-VxxxBGHT
N 914CBT-H760DHT
N 914CBT-H760BHT
N 929CBT-V560GHT
N 929CBT-V560BGHT 929CBT-VxxxBGHT
N 929CBT-V760GHT
N 929CBT-V760BGHT 929CBT-VxxxBGHT
N 929CBT-V760GHT
N 929CBT-V760BGHT 929CBT-VxxxBGHT
N 930CBT-V760GHT
N 930CBT-V760BGHT 930CBT-VxxxBGHT
N 930CBT-V760GHT
N 930CBT-V760BGHT 930CBT-VxxxBGHT
N 917CM15
N 917CM17
N 917CM25
N 917CM15
N 917CM17
N 917CM27
N 917CM17
N 917CM25
N 917CM27
N 917CM27
N 917CM25
N 917CM27
N 917CM37
N 917CM27
N 917CM37
N 917CMD27
N 917CM27
N 917CM37
N 917CMD27
N 917CM37
N 917CMD37
N 917CM37
N 917CMD37
N 917CMD27
N 917CM17
N 917CMD27
N 917CM25
N 917CMD37
N 917CMD37
Danfoss A/S © Rev. 05/2014 All rights reserved.
Drawing type
914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
917CM15 chapter 9.7.9 Figure 9 - 917CM15
917CM17 chapter 9.7.10 Figure 10 - 917CM17
917CM25 chapter 9.7.11 Figure 11 - 917CM25
917CM15 chapter 9.7.9 Figure 9 - 917CM15
917CM17 chapter 9.7.10 Figure 10 - 917CM17
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM17 chapter 9.7.10 Figure 10 - 917CM17
917CM25 chapter 9.7.11 Figure 11 - 917CM25
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM25 chapter 9.7.11 Figure 11 - 917CM25
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM37 chapter 9.7.13 Figure 13 - 917CM37
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM37 chapter 9.7.13 Figure 13 - 917CM37
917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
917CM27 chapter 9.7.12 Figure 12 - 917CM27
917CM37 chapter 9.7.13 Figure 13 - 917CM37
917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
917CM37 chapter 9.7.13 Figure 13 - 917CM37
917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
917CM37 chapter 9.7.13 Figure 13 - 917CM37
917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
917CM17 chapter 9.7.10 Figure 10 - 917CM17
917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
917CM25 chapter 9.7.11 Figure 11 - 917CM25
917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
Drawing reference
77
9 9
