Figure 17 - 929Cbt-Vxxxbght - Danfoss VLT Brake Resistor MCE 101 Design Manual

Specifications

9.7.17 Figure 17 - 929CBT-VxxxBGHT

[3.15]
80
9 9
1 Hot surface warning x3
2 Name plate
Illustration 9.85 IP65, Side View and Top View
Danfoss code
175U3052
175U3058
175U3064
175U3066
175U3071
175U3135
175U3143
175U3149
175U3157
175U3175
175U3177
122
Design Guide
1
[L + 5.31]
2
L + 135
[0.53]
13.5
Typecode
MCE101A15R5P3K50E65TAW
MCE101A13R5P4K20E65TAW
MCE101A11R0p5K50E65TAW
MCE101A9R50P4K20E65TAW
MCE101A7R00P5K50E65TAW
MCE101A105RP4K20E65TAW
MCE101A72R0P4K20E65TAW
MCE101A52R0P5K50E65TAW
MCE101A38R0P5K50E65TAW
MCE101A13R0P3K50E65TAW
MCE101A9R00P5K50E65TAW
Danfoss A/S © Rev. 05/2014 All rights reserved.
L
L
L1
L±2
Ω
L±0.08 in
mm
15,5 560 22.05
13,5 660 25.95
11 760 29.92
9,5 660 25.95
7 760 29.92
105 660 25.95
72 660 25.95
52 760 29.92
38 760 29.92
13 560 22.05
9 760 29.92
L1±2 mm L1±0.04 in Weight [kg]
530 20.87 26.5
630 24.8 30
730 28.74 33.5
630 24.8 30
730 28.74 33.5
630 24.8 30
630 24.8 30
730 28.74 33.5
730 28.74 33.5
530 20.87 26.5
730 28.74 33.5
