Danfoss VLT Brake Resistor MCE 101 Design Manual page 38

Selection Guide
10% duty cycle, horizontal braking, T4
Frequency converter data
Mains P
m
type [kW]
T4 1.1
T4 1.5
T4 2.2
T4 3
T4 4
T4 5.5
T4 7.5
T4 11
T4 15
T4 18.5
T4 22
T4 30
T4 37
8 8
T4 45
T4 55
T4 75
T4 90
T4 110
T4 132
T4 160
T4 200
T4 250
T4 315
T4 355
T4 400
T4 450
T4 500
T4 560
T4 630
T4 710
T4 800
T4 1000
Table 8.5 T4, Horizontal Braking 10% Duty Cycle
36
Design Guide
FC 102
R R R
min br,nom rec
[Ω] [Ω] [Ω]
546 607.3 630
382 437.3 410
260 293.3 270
189 212.7 200
135 157.3 145
99.0 113.3 110
72.0 82.4 80
50.0 55.3 56
36.0 40.3 38
27.0 32.5 28
20.3 27.2 22
18.0 19.8 19
13.4 16.0 14
10.8 13.1 12
8.8 10.7 9.5
6.5 7.8 7.0
4.2 6.5 5.5
3.6 5.3 4.7
3.0 4.4 3.7
2.5 3.6 3.3
2.0 2.9 2.7
1.6 2.3 2.1
1.2 1.8 1.7
1.2 1.6 1.3
1.2 1.4 1.2
1.1 1.3 1.1
0.9 1.1 2x1.9
0.9 1.0 2x1.7
0.8 0.9 2x1.5
0.7 0.8 2x1.3
0.6 0.7 3x1.8
0.5 0.6 3x1.6
Danfoss A/S © Rev. 05/2014 All rights reserved.
Horizontal braking 10% duty cycle
Brake resistor data
Danfoss part number
Screw
P Wire IP54 terminal
br,cont.
[kW] IP21
0.100 175u3002 -
0.100 175u3004 -
0.200 175u3007 -
0.200 175u3008 -
0.300 175u3300 -
0.450 175u3335 175u3450
0.570 175u3336 175u3452
0.680 175u3337 175u3027
1.130 175u3338 175u3034
1.400 175u3339 175u3039
1.700 175u3340 175u3047
2.200 175u3357 175u3049
2.800 175u3341 175u3055
3.200 175u3359 175u3061
4.200 - 175u3065
5.500 - 175u3070
7.000 - -
9.000 - -
11.000 - -
13.000 - -
16.000 - -
20.000 - -
26.000 - -
32.000 - -
36.000 - -
42.000 - -
- - -
- - -
- - -
- - -
- - -
- - -
Installation
Cable
cross-
Screw Bolt
section
terminal connection
[mm 2 ]
IP65 IP20
- - 1.5
- - 1.5
- - 1.5
- - 1.5
- - 1.5
175u3449 - 1.5
175u3451 - 1.5
175u3028 - 1.5
175u3035 - 1.5
175u3040 - 1.5
175u3048 - 1.5
175u3050 - 1.5
175u3056 - 2.5
175u3062 - 2.5
175u3066 - 4
175u3071 - 6
- 175u3231 10
- 175u3079 16
- 175u3083 25
- 175u3084 35
- 175u3088 50
- 175u3091 70
- 175u3093 2x35
- 175u3097 2x35
- 175u3098 2x50
- 175u3099 2x50
- - -
- - -
- - -
- - -
- - -
- - -
Thermo
relay
[A]
0.4
0.5
0.8
0.9
1.3
1.9
2.5
3.3
5.2
6.7
8.3
10.1
13.3
15.3
20
26
36
44
55
63
77
98
124
157
173
196
-
-
-
-
-
-
MG90O202
