5.7~19" Arm-based HMI
Freescale® Cortex® A9 i.MX6 Dual Core, 1 GHz
Android 6.0
Front IP65
Model No.: R05FA3S-IPD1HMHB
W07FA3S-IPA3HM
W10FA3S-IPH1HM
R15FA3S-IPC3HM
R19FA3S-IPM1HM
User Manual
Document Version 1.0
Document Part Number: 91521110103V
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winmate R05FA3S-IPD1HMHB
Summary of Contents for Winmate R05FA3S-IPD1HMHB
- Page 1 5.7~19” Arm-based HMI Freescale® Cortex® A9 i.MX6 Dual Core, 1 GHz Android 6.0 Front IP65 Model No.: R05FA3S-IPD1HMHB W07FA3S-IPA3HM W10FA3S-IPH1HM R15FA3S-IPC3HM R19FA3S-IPM1HM User Manual Document Version 1.0 Document Part Number: 91521110103V Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
Arm-based Front IP65 HMI User Manual Contents Preface ..........................4 About This User Manual ..................... 9 Chapter 1: Introduction ....................10 1.1 Introduction ......................11 1.2 Product Features ....................11 1.3 Package Contents ....................11 1.4 Connector Description ..................12 1.5 Mechanical Dimensions .................. - Page 3 4.4 Ethernet ......................32 4.4.1 Configuring Ethernet ................. 33 4.4.2 Checking Ethernet Settings ..............34 4.5 Winmate® Home Manager (WHM)..............35 4.5.1 How to Lock Applications ................35 4.5.2 How to Unlock Applications ..............38 4.5.3 How to Change Password ................ 39 Chapter 5: Software Installation ..................
-
Page 4: Preface
Arm-based Front IP65 HMI User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
- Page 6 Arm-based Front IP65 HMI User Manual Safety Information Warning!/ Avertissement! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
- Page 7 Preface *Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged. o Liquid has penetrated into the equipment. o The equipment has been exposed to moisture. o The equipment does not work well or you cannot get it to work according to the user manual.
- Page 8 Arm-based Front IP65 HMI User Manual Important Information Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including ...
-
Page 9: About This User Manual
About This User Manual About This User Manual This User Manual provides information about using the Winmate® Arm-based Front IP65 HMI. This User Manual applies to the Arm-based Front IP65 HMI. The documentation set for the Arm-based Front IP65 HMI with Freescale® Cortex® A9 i.MX6 Dual Core provides information for specific user needs, and includes: ... -
Page 10: Chapter 1: Introduction
Arm-based Front IP65 HMI User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter. -
Page 11: Introduction
Chapter 1: Introduction 1.1 Introduction Congratulations on purchasing Winmate® Arm-based Front IP65 HMI. Winmate continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). Our Arm-based Front IP65 HMI runs on Android 6.0 operating system that allows installing the latest applications (APPs). -
Page 12: Connector Description
Arm-based Front IP65 HMI User Manual 1.4 Connector Description Terminal interfaces are located on the bottom side of the HMI device. Note: Notice that input and output connectors vary by product size and specifications. Terminal interfaces description: Item Description RJ45 – Connects HMI device to Ethernet network. Supports PoE for power transmission in network equipment, via network UTP cable, together with data. -
Page 13: Mechanical Dimensions
Chapter 1: Introduction 1.5 Mechanical Dimensions This section describes physical appearance of the HMI. The picture above shows only a prototype model for information purposes only. 5.6-inch, R05FA3S-IPD1HMHB Unit: mm Dimensions : 188 x 148 x 59 Cutout Dimensions: 162 x 118... - Page 14 Arm-based Front IP65 HMI User Manual 10.1-inch, W10FA3S-IPH1HM Unit: mm Dimensions : 286 x 176 x 49.5 Cutout Dimensions: 239 x 162 15-inch, R15FA3S-IPC3HM Unit: mm Dimensions : 400 x 292 x 59 Cutout Dimensions: 360 x 292...
- Page 15 Chapter 1: Introduction 19-inch, R19FA3S-IPM1HM Unit: mm Dimensions : 474 x 384 x 71.4 Cutout Dimensions: 432.5 x 342.5...
-
Page 16: Chapter 2: Getting Started
Arm-based Front IP65 HMI User Manual Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. -
Page 17: Powering On
Chapter 2: Getting Started 2.1 Powering On 2.1.1 AC Adapter Components 2 Pin Terminal Block Power Cord AC Adapter to DC Jack Safety Precautions: Do not use the adapter in a high moisture environment Never touch the adapter with wet hands or foot ... -
Page 18: Connecting The Power
Arm-based Front IP65 HMI User Manual 2.1.3 Connecting the Power Installation Instruction: Connect a 2-pin terminal block to the HMI connector. Connect the other side of the terminal block to the AC adapter. Connect the AC adapter to the power cord. Plug in the power cord to a working AC wall outlet. -
Page 19: Connector Description
TxD+ RxD+ RxD- “Configuring Serial port settings can be configured in Winmate application for Android OS. Refer to Settings” of this User Manual for more details. Serial Port 2.2.3 Ethernet Connector The HMI device supports one RJ45 10/100/1000 Mbps Ethernet interface for connecting to the internet. -
Page 20: Usb 2.0 Connector
Arm-based Front IP65 HMI User Manual 2.2.4 USB 2.0 Connector Use USB A Type (USB 2.0) connector to connect your device to other USB 2.0 compatible devices. Pin assignments and signal name USB 2.0 connector Pin № Pin № Signal Name Signal Name USB_D- USB_D+... -
Page 21: Micro Hdmi Connector
Chapter 2: Getting Started 2.2.7 Micro HDMI Connector The HMI has one Micro HDMI connector. Pin assignments and signal name of micro HDMI connector Pin № Pin № Signal Name Signal Name HP_DET_OUT HDMI_D2P HDMI_D2M HDMI_D1P HDMI_D1M HDMI_D0P HDMI_D0M HDMI_CLKP HDMI_CLKM 2.3 Turning On and Off the HMI Device This section describes how to turn on and off the HMI device. -
Page 22: Configuring Serial Port Settings
Arm-based Front IP65 HMI User Manual 2.4 Configuring Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. To configure serial port settings: 1. Settings > Accessibility. - Page 23 Chapter 2: Getting Started 3. Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings...
-
Page 24: Chapter 3: Mounting
Arm-based Front IP65 HMI User Manual Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. -
Page 25: Cable Mounting Considerations
Chapter 3: Mounting 3.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the HMI device. Caution/ Attention Observe all local installation requirements for connection cable type and protection level. Suivre tous les règlements locaux d’installations, de câblage et niveaux de protection. -
Page 26: Panel Mount
Arm-based Front IP65 HMI User Manual 3.3.1 Panel Mount The HMI device comes with clamp mounts that enable you to install the unit onto a wall (where space has been cut out to accommodate the rest of the hardware). Size Cutout Mounting clips 5.7”... -
Page 27: Vesa Mount
VESA M4, H = 4 mm Installation Instruction: 1. Screw VESA bracket to the fixture (ex. swing arm) with four VESA screws. 2. Place the device on VESA bracket. Notice that VESA stand and mounting kit are not provided by Winmate. -
Page 28: Chapter 4: Operating The Device
Arm-based Front IP65 HMI User Manual Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device. -
Page 29: Operating System
Chapter 4: Operating the Device 4.1 Operating System HMI supports Android 6.0. Important: The watchdog timer is set by default. The system will automatically reboot if it hangs after 30 seconds. If the app hangs, watchdog function will not be activated. 4.2 Multi-Touch The touchpad supports the core gestures for Android. -
Page 30: System Settings
Arm-based Front IP65 HMI User Manual 4.3 System Settings This section explains how to adjust main system settings in Android 6.0. 4.3.1 Set up the Device When you first turn on your HMI device, you’ll see a Welcome screen. Choose the language you want and touch Start or the Start icon. -
Page 31: Quick Settings
Chapter 4: Operating the Device Some apps hide these buttons temporarily, or fade them to small dots in the same position. To bring them back, touch the dots, touch the screen in the middle, or swipe up from the bottom. Many screens in apps and Settings include a menu icon at the top right of the screen. -
Page 32: Ethernet
Arm-based Front IP65 HMI User Manual 4.4 Ethernet 1. Connect Ethernet Cable to the HMI. 2. Touch All APPS icon, and the open Ethernet application. 3. Ethernet APP main menu appears... -
Page 33: Configuring Ethernet
Chapter 4: Operating the Device 4.4.1 Configuring Ethernet Go to All Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway... -
Page 34: Checking Ethernet Settings
Arm-based Front IP65 HMI User Manual 4.4.2 Checking Ethernet Settings To check Ethernet settings: Go to All Apps > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. -
Page 35: Winmate® Home Manager (Whm)
Chapter 4: Operating the Device 4.5 Winmate® Home Manager (WHM) Winmate® Arm-based HMI comes with preinstalled APP called Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. - Page 36 Arm-based Front IP65 HMI User Manual Menu Description Home Manager Set which app you want to run up automatically after booting Set the WHM password (Default password is “0000”). Password Manager About Displays information about Home Manager 2. Go to “Application Selector”, and choose the app which you want to run up automatically after booting.
- Page 37 Chapter 4: Operating the Device 3. Go back to “Home Selector” and press “Clear and Reset Default Home”. 4. Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Any time user presses home key or back key;...
-
Page 38: How To Unlock Applications
Arm-based Front IP65 HMI User Manual 4.5.2 How to Unlock Applications Follow the instruction below to reset Home Manager. 1. If you want to reset the home manager, pull down the left side to open the status bar and open HomeManager. -
Page 39: How To Change Password
Chapter 4: Operating the Device 3. Restart the system and you will go back to the normal Launcher. 4.5.3 How to Change Password To change the password: 1. Go to Password Manager and set your own password for this APP. 2. -
Page 40: Chapter 5: Software Installation
Arm-based Front IP65 HMI User Manual Chapter 5: Software Installation This chapter contains software installation and updates guide. All the programming guides can be found in the driver CD included in the package. -
Page 41: Android Debug Bridge (Adb) Driver Installation
Chapter 5: Software Installation 5.1 Android Debug Bridge (ADB) Driver Installation Important: If your computer is running on Windows Embedded 8 Standard or Windows 8.1 Industry Pro OS system, you need to disable driver signature. For Win XP / Win 7 skip disabling driver signature section, and directly proceed to ADB driver installation. -
Page 42: Disabling Driver Signature On Windows 8
Arm-based Front IP65 HMI User Manual 5.1.1 Disabling Driver Signature on Windows 8 1. Hold down the Windows key on your keyboard and press the letter C to open the Charm menu, and then click the gear icon (Settings). 2. Click Change PC Settings. - Page 43 Chapter 5: Software Installation 3. Click General. 4. Under Advanced Startup, click Restart Now. NOTE: In Windows 8.1, the ‘Restart Now’ button has moved to ‘PC Setting -> Update & Recovery -> Recovery.’ 5. After restarting, click Troubleshoot. 6. Click Advanced Options.
- Page 44 Arm-based Front IP65 HMI User Manual 7. Click Windows Startup Settings.
- Page 45 Chapter 5: Software Installation 8. Click Restart. 9. After restarting your computer a second time, choose Disable driver signature enforcement from the list by typing the number 7 on your keyboard. Your computer will restart automatically.
-
Page 46: Adb Driver Installation
Arm-based Front IP65 HMI User Manual 10. After restarting, you will be able to install the ADB drivers normally; however, Windows will display a warning message. When the warning appears, click Install this driver software anyway. If you are unfamiliar with installing drivers, check out our Installing ADB driver tutorial for a step by step guide. - Page 47 Chapter 5: Software Installation 2. In the Update Driver Software window choose Browse my computer for driver software. 3. Select Let me pick from a list of device drivers on my computer. Click Next. 4. Select from your computer 5. In the Update driver software window, click show All Devices and then click Next.
- Page 48 Arm-based Front IP65 HMI User Manual 6. The system is looking for the driver folder. Click Browse. 7. Select the driver for your OS system. Click Open.
- Page 49 Chapter 5: Software Installation 8. Windows Security window will pop up. This message is used to confirm whether the user wants to install the driver. Select Install this driver software anyway to continue. 9. When the installation is successfully completed you will see Android ADB Interface driver in the Update Driver Software window.
-
Page 50: Installing Android Debug Bridge (Adb)
Arm-based Front IP65 HMI User Manual 5.2 Installing Android Debug Bridge (ADB) For detailed Android Debug Bridge (ADB) information refer to Android Developers Platform: http://developer.android.com/tools/help/adb.html 5.2.1 Installing Android Debug Bridge (ADB) 1. Decompress adb.zip. Open ADB terminal and move into the adb archive. ADB Terminal window 2. - Page 51 Chapter 5: Software Installation 4. Get dmesg dmesg 2>&1 | tee /storage/sdcard1/dmesg .log 5. Get logcat commad a. logcat 2>&1 | tee storage/sdcard1/logcat.log b. When the get action stops, press "Ctrl + C" to leave logcat.
-
Page 52: Downloading Image Tool
Arm-based Front IP65 HMI User Manual 5.3 Downloading Image Tool Download OS Image Tool update guide from Winmate Download Center. http://www.winmate.com/ > Support > Download Center > Panel PC > ARM 5.4 OTA Update Guide OTA is a tool which can help you to update OS image. To receive Android OS image file contact our sales representatives. - Page 53 Chapter 5: Software Installation System shows OTA firmware related information. 3. Click Auto-check Update. The system is checking OTA File. It may take some time.
- Page 54 Arm-based Front IP65 HMI User Manual 4. Tap Update Image 5. Make sure the file founded by the system is image update file. Tap OK.
- Page 55 Chapter 5: Software Installation 6. Make sure the battery level is at least 50%. Tap OK. 7. Tap OK. Important: Do not disconnect the power source! Do not remove the battery!
-
Page 56: Os Image Update Guide
Arm-based Front IP65 HMI User Manual 8. After update the system will automatically restart. 5.5 OS Image Update Guide Contact our technical support at to receive the latest OS image available for your device. -
Page 57: Chapter 6: Technical Support
Chapter 6: Technical Support Chapter 6: Technical Support This chapter includes the directory for technical support. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. -
Page 58: Introduction
To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center. Winmate provides the following Drivers for Arm-based HMI with Freescale® Cortex® A9 i.MX6 Dual Core 1GHz processor:... -
Page 59: Appendix A: Product Specifications
Appendix A: Product Specifications Appendix A: Product Specifications Hardware Specifications Model Name R05FA3S- W07FA3S- W10FA3S- R15FA3S- R19FA3S- IPD1HMHB IPA3HM IPH1HM IPC3HM IPM1HM Display 5.7” 7” 10.1” 15” 19” Size Resolution 640 x 480 1024 x 600 1024 x 600 1024 x 768 1280 x 1024 Brightness 900 nits... - Page 60 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
