Winmate R05FA3S-OFD1HMHB User Manual

5.7-19” arm-based hmi freescale cortex a9 i.mx6 dual core, 1 ghz android 6.0, open frame
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5.7~19" Arm-based HMI
Freescale® Cortex® A9 i.MX6 Dual Core, 1 GHz
Android 6.0
Open Frame
Model No.: R05FA3S-OFD1HMHB
W07FA3S-OFA3HM
W10FA3S-OFH1HM
R15FA3S-OFC3HM
R19FA3S-OFM1HM
User Manual
Document Version 1.1
Document Part Number: 91521110103W
Please read these instructions carefully before using this product, and save this manual for future use.
