E-Series HMI
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
Elegant Design
Model No.: W07IB3S-EHT1
W10IB3S-EHH2
R15IB3S-EHC3
W15IB3S-EHA4
User Manual
Document Version 1.4
Document Part No.9152101I1003
Please read this instructions before operating the device and retain them for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Winmate W15IB3S-EHA4

Summary of Contents for Winmate W15IB3S-EHA4

  • Page 1 E-Series HMI Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Elegant Design Model No.: W07IB3S-EHT1 W10IB3S-EHH2 R15IB3S-EHC3 W15IB3S-EHA4 User Manual Document Version 1.4 Document Part No.9152101I1003 Please read this instructions before operating the device and retain them for future reference.

  • Page 2: Table Of Contents

    7~15.6" E-Series HMI Quick Start Guide Contents About This User Manual ......................7 Chapter 1: Introduction ......................8 1.1 Overview ......................9 1.2 Product Features ....................9 1.3 Package Contents ....................9 1.4 Description of Parts .................... 10 Chapter 2: Getting Started ..................... 13 2.1 Powering On ......................
  • Page 3 About This User Manual 6.1 Chipset Driver..................... 53 6.2 Graphic Driver ....................55 6.3 Intel Sideband Fabric Device (Intel MBI) Driver ..........56 6.4 Intel Trusted Engine Interface (Intel TXE) Driver ..........57 6.5 Intel Network Connections ................. 58 6.6 Audio Driver ....................... 59 6.7 Watchdog Driver....................
  • Page 4 7~15.6" E-Series HMI Quick Start Guide FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received including ...
  • Page 5 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
  • Page 6 7~15.6" E-Series HMI Quick Start Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.

  • Page 7: About This User Manual

    About This User Manual About This User Manual This User Manual provides information about using the Winmate® E-Series HMI. This User Manual applies to the E-Series HMI – W07IB3S-EHT1, W10IB3S-EHH2 and W15IB3S-EHA2. The documentation set for the E-Series HMI with Intel® Celeron® Bay Trail-M N2930 1.83 GHz processor provides information for specific user needs, and includes: ...

  • Page 8: Chapter 1: Introduction

    7~15.6" E-Series HMI Quick Start Guide Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter.

  • Page 9: Overview

    Chapter 1: Introduction 1.1 Overview Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). You can choose the most suitable operating system for you application. Thereby wide customization possibilities are available to satisfy the needs of industrial automation.

  • Page 10: Description Of Parts

    7~15.6" E-Series HMI Quick Start Guide 1.4 Description of Parts This section describes appearance, connectors’ layout and mechanical dimensions of E-Series HMI. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information. E-Series HMI 7”...
  • Page 11 Chapter 1: Introduction E-Series HMI 10.1” Unit: mm № № Description Description ① 12V DC Power Jack ④ HDMI 1.4a ② ⑤ RS-232/422/485 RJ-45 Gbe LAN x 2 ③ USB 3.0 x 1, USB 2.0 x 1 E-Series HMI 15” Unit: mm №...
  • Page 12 7~15.6" E-Series HMI Quick Start Guide E-Series HMI 15.6” Unit: mm № № Description Description ① ④ 12V DC Power Jack HDMI 1.4a ② ⑤ RS-232/422/485 RJ-45 Gbe LAN x 2 ③ USB 3.0 x 1, USB 2.0 x 1...

  • Page 13: Chapter 2: Getting Started

    Chapter 2: Getting Started Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations.

  • Page 14: Powering On

    7~15.6" E-Series HMI Quick Start Guide 2.1 Powering On AC Adapter Components  AC Adapter  Power Cord 12V/ 50W Safety Precautions:  Do not use the adapter in a high moisture environment  Never touch the adapter with wet hands or foot ...

  • Page 15: Turning On/ Off Your Device

    Chapter 2: Getting Started 2.2 Turning On/ Off Your Device The HMI device operates on external DC power. Use the AC adapter included in the package. CAUTION/ATTENTION Use only the AC adapter included in your package. Using other AC adapters may damage the device. Utiliser seulement le convertisseur AC inclu avec votre appareil.

  • Page 16: Connecting To Other Devices

    7~15.6" E-Series HMI Quick Start Guide 2.3 Connecting to Other Devices 2.3.1 Power Connector DC power source input is a power jack connector. Power input is 12V DC. Pin № Pin № Signal Name Signal Name DC_IN Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A Voltage...

  • Page 17: Usb Connector

    Chapter 2: Getting Started 2.3.4 USB Connector E-Series HMI has USB 2.0 and USB 3.0 connectors. Use USB cable to connect the HMI to other external devices such as a keyboard or mouse. Pin № Pin № Signal Name Signal Name USB_D- USB_D+ STDA_SSRX-...

  • Page 18: Configuring Serial Port Settings

    7~15.6" E-Series HMI Quick Start Guide 2.4 Configuring Serial Port Settings Serial port COM1 can be configured for RS-232, RS-422 or RS-485. Jumpers are located on the motherboard. You need to open the housing in order to access the jumpers. CAUTION/ ATTENTION It is recommended to use factory jumper settings.

  • Page 19: Chapter 3: Mounting

    Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. Please read this instructions before operating the device and retain them for future reference.

  • Page 20: Wiring Requirements

    7~15.6" E-Series HMI Quick Start Guide 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 21: Mounting Solution

    Chapter 3: Mounting 3.2 Mounting Solution 3.2.1 Panel Mount In addition to elegant design, panel mount solution is making the HMI unit easy to clean and maintain. The HMI device is secured to the fixture from the rear by using the mounting brackets included in the package.

  • Page 22: Vesa Mount

    3.2.2 VESA Mount VESA Mount is a widely used mounting solution suitable for all kinds of applications. Notice that VESA mounting solution applies only to 7” E-Series HMI. Notice that VESA mounting kit is not supplied by Winmate. Dimensions Screw Hole Diameter...

  • Page 23: Chapter 4: Operating The Device

    Chapter 4: Operating the Device Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device.

  • Page 24: Operating System

    7~15.6" E-Series HMI Quick Start Guide 4.1 Operating System E-series HMI support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7 – WS7P. IMPORTANT: The device is shipped with the OS System according to your order.

  • Page 25: How To Enable Watchdog

    4.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details.

  • Page 26: Chapter 5: Ami Uefi Bios Setup

    7~15.6" E-Series HMI Quick Start Guide Chapter 5: AMI UEFI BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.

  • Page 27: When And How To Use Bios Setup

    Chapter 5: AMI UEFI BIOS Setup 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>...

  • Page 28: Main Menu

    7~15.6" E-Series HMI Quick Start Guide NOTE: You can press the F1, F2, F3, F4, –/+, and Esc keys by connecting a USB keyboard to your device. For items marked ► press <Enter> for more options. 5.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu. It contains the system information including BIOS version, processor RC version, system language, time, and date.

  • Page 29: Advanced Menu

    Chapter 5: AMI UEFI BIOS Setup 5.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer.
  • Page 30 7~15.6" E-Series HMI Quick Start Guide BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI Enter Opens submenu settings F81866 Super IO Configures IO Enter Opens submenu Configuration settings Hardware Monitor Configures Enter Opens submenu Hardware Monitor settings S5 RTC Wake Configures RTC Enter Opens submenu...
  • Page 31 Chapter 5: AMI UEFI BIOS Setup 5.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
  • Page 32 7~15.6" E-Series HMI Quick Start Guide 5.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen. For items marked with ►, please press <Enter>...
  • Page 33 Chapter 5: AMI UEFI BIOS Setup 5.2.2.2.3 GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 5.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc.
  • Page 34 7~15.6" E-Series HMI Quick Start Guide 5.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time. 5.2.2.4.1 Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time.
  • Page 35 Chapter 5: AMI UEFI BIOS Setup 5.2.2.4.2 Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). 5.2.2.5 CPU Configuration...
  • Page 36 7~15.6" E-Series HMI Quick Start Guide BIOS Setting Description Setting Option Effect Socket CPU This item contains Enter Open sub-menu Information socket specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Disabled/Enabled Enable/Disable Maximum Maximum this function Execute Disable...
  • Page 37 Chapter 5: AMI UEFI BIOS Setup 5.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Setting Description Setting Option Effect Critical Trip Point Specifies the...
  • Page 38 7~15.6" E-Series HMI Quick Start Guide 5.2.2.8 IDE Configuration...
  • Page 39 Chapter 5: AMI UEFI BIOS Setup BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this function (SATA) supporting chipset drives Disabled with SATA interface. SATA Speed Allows forcing the speed Gen1 The maximum speed will be Support limit SATA II ports limited to 150 MB/s...
  • Page 40 7~15.6" E-Series HMI Quick Start Guide 5.2.2.9 Miscellaneous Configuration OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Option Effect Windows 8.X Allows user to Enter Use Windows choose the proper OS. Windows 7 Allows user to Enter Use Windows 7...
  • Page 41 Chapter 5: AMI UEFI BIOS Setup 5.2.2.10 CSM Configuration BIOS Setting Description Setting Option Effect CSM Support The Compatibility Support Enabled/ Enable or disable the Module (CSM) is a Disabled Compatibility Support component of the UEFI Module firmware that provides legacy BIOS compatibility by emulating a BIOS environment, allowing legacy...
  • Page 42 7~15.6" E-Series HMI Quick Start Guide 5.2.2.11 USB Configuration BIOS Setting Description Setting Effect Option Legacy USB User can enable or Disable Will keep USB devices Support disable USB port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 Support User can enable or Enable...
  • Page 43 Chapter 5: AMI UEFI BIOS Setup 5.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Module Enabled/Disabled Enables or parameters disables this function 5.2.2.13 Security Configuration...

  • Page 44: Chipset Menu

    7~15.6" E-Series HMI Quick Start Guide BIOS Setting Description Setting Effect Option Trusted Execution Enabled/ Enables or disables Technology Disabled this function parameters TXE HMRFPO TXE HMRFPO Enabled/ Enables or disables parameters Disabled this function TXE Firmware Update TXE Firmware Enabled/ Enables or disables Update parameters...

  • Page 45: Security Menu

    Chapter 5: AMI UEFI BIOS Setup 5.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Option Effect Administrator Displays whether Enter Enter password Password or not an administrator password has been set.

  • Page 46: Boot Configuration

    7~15.6" E-Series HMI Quick Start Guide 5.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.
  • Page 47 Chapter 5: AMI UEFI BIOS Setup BIOS Setting Description Setting Option Effect Setup Prompt Allows user to Enter Set the prompt Timeout configure the timeout number of seconds to stay in BIOS setup prompt screen. Boot NumLock State Enables or disables Remains On NumLock feature on the numeric keypad...

  • Page 48: Save & Exit

    7~15.6" E-Series HMI Quick Start Guide 5.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied.
  • Page 49 Chapter 5: AMI UEFI BIOS Setup BIOS Setting Description Setting Option Effect Save Changes and This saves the Enter <YES> Save changes Exit changes to the CMOS and exits the BIOS Setup program. Discard Changes This exits the BIOS Enter <YES> Saves the changes and Exit Setup without saving...

  • Page 50: Using Recovery Wizard To Restore Computer

    7~15.6" E-Series HMI Quick Start Guide 5.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ...
  • Page 51 Chapter 5: AMI UEFI BIOS Setup Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The system will restart automatically after recovery completed.

  • Page 52: Chapter 6: Driver Installation

    7~15.6" E-Series HMI Quick Start Guide Chapter 6: Driver Installation This chapter provides guideline to driver installations.

  • Page 53: Chipset Driver

    Chapter 6: Driver Installation 6.1 Chipset Driver Follow instructions below to install Chipset driver. 1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. 2. Click Next to continue. 3.
  • Page 54 7~15.6" E-Series HMI Quick Start Guide 4. Click Next to install the driver. 5. Software setup progress window will appear, click Next to continue. 6. Click “Yes, I want to restart this computer now” to finish the installation.

  • Page 55: Graphic Driver

    Chapter 6: Driver Installation 6.2 Graphic Driver Follow instructions below to install Graphic driver. 1. Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. 2. Setup Welcome Window will appear, click Next to continue the process. 3.

  • Page 56: Intel Sideband Fabric Device (Intel Mbi) Driver

    7~15.6" E-Series HMI Quick Start Guide 6.3 Intel Sideband Fabric Device (Intel MBI) Driver Only for Windows 8.OS. Follow instructions below to install Intel MBI driver. 1. Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe”...

  • Page 57: Intel Trusted Engine Interface (Intel Txe) Driver

    Chapter 6: Driver Installation 6.4 Intel Trusted Engine Interface (Intel TXE) Driver Follow instructions below to install Intel TXE driver. 1. Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. 2.

  • Page 58: Intel Network Connections

    7~15.6" E-Series HMI Quick Start Guide 6.5 Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Follow instructions below to install Intel Network Connections driver. 1.

  • Page 59: Audio Driver

    Chapter 6: Driver Installation 6.6 Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.

  • Page 60: Watchdog Driver

    7~15.6" E-Series HMI Quick Start Guide 6.7 Watchdog Driver For more details about Winmate Watchdog, please download Watchdog Guide from Winmate Downloads Center: http://dc.winmate.com.tw/_downloadCenter/2017/Embedded%20Computing/Watchdog%20Guide_ IB_IH_IV_IK.pdf Follow instructions below to install Watchdog driver. 1. Open the Driver CD (included in the package) and select Watchdog driver.

  • Page 61: Chapter 7: Technical Support

    Chapter 7: Technical Support Chapter 7: Technical Support This chapter includes the directory for technical support. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products.

  • Page 62: Introduction

    7~15.6" E-Series HMI Quick Start Guide 7.1 Introduction Winmate provides the following SDK and Utilities for E-Series HMI with Intel® Celeron® Bay Trail- M N2930: Item File Type Description Watchdog SDK Utility Watchdog Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us.

  • Page 63: Appendix

    Appendix Appendix Appendix A: Hardware Specifications Model Name W07IB3S-EHT1 W10IB3S-EHH2 R15IB3S-EHC3 W15IB3S-EHA4 Display 7” (Wide) 10.1” (Wide) 15” Size/ Type 15.6" (Wide) Resolution 1024x600 1280 x 800 1024 x 768 1366 x 768 Brightness 320 nits 350 nits 300 nits...
