IP65 Stainless Resistive
15"/ 17"/ 19"/ 21.5"/ 23.8" Panel PC
8th Generation (Whiskey Lake) Intel® Core™ i5-8265U 1.6GHz (turbo to 3.9GHz)
Quick Start Guide
Version 1.0
Document Part No. 91521110108I
Please read this instructions before operating the device and retain them for future reference.
Model No. R15IW3S-65C3
R17IW3S-65M1
R19IW3S-65M1
W22IW3S-65A3
W24IW3S-65A2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winmate R15IW3S-65C3
Summary of Contents for Winmate R15IW3S-65C3
- Page 1 IP65 Stainless Resistive 15”/ 17”/ 19”/ 21.5”/ 23.8” Panel PC 8th Generation (Whiskey Lake) Intel® Core™ i5-8265U 1.6GHz (turbo to 3.9GHz) Model No. R15IW3S-65C3 R17IW3S-65M1 R19IW3S-65M1 W22IW3S-65A3 W24IW3S-65A2 Quick Start Guide Version 1.0 Document Part No. 91521110108I Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
2.3 Mounting 2.3.1 VESA Mount 2.3.2 Yoke Mount Chapter 3: Getting Started 3.1 Turning On and Off Your Device 3.2 How to Enable Watchdog Appendix Appendix A: Hardware Specifications Appendix B: Winmate Software Development Kit Appendix C: Cleaning the Monitor... - Page 3 Chapter 1: Introduction FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. ⚫ This device must accept any interference received including ⚫ interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
- Page 4 Warranty Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer discovers a defect, we will, at his/her option, repair or replace the defective product at no charge to the customer, provide it is returned during the warranty period of one year, with transportation charges prepaid.
- Page 5 Chapter 1: Introduction Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
-
Page 6: Chapter 1: Introduction
Chapter 1: Introduction Congratulations on purchasing Winmate® IP65 Stainless Resistive Panel PC. Winmate flat stainless steel PCAP panel PCs and display are designed for applications with high hygienic requirements. IP65 series is completely waterproof with IP65 level of protection. The IP65 stainless series work well in food, beverage industry, including food processing operations and packaging, chemical manufacturing and other industrial applications. -
Page 7: Package Content
Chapter 1: Introduction 1.2 Package Content Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard shipment list: •... -
Page 8: Product Overview
IP65 Stainless Resistive Panel PC Quick Start Guide 1.3 Product Overview This section contains mechanical drawing of the Panel PC. Notice that this is a simplified drawing and some components are not marked in detail. 1.3.1 Dimensions 15" Unit: mm 1.3.2 Dimensions 17”... -
Page 9: Dimensions 19
Chapter 1: Introduction 1.3.3 Dimensions 19” Unit: mm 1.3.4 Dimensions 21.5” Unit: mm... -
Page 10: Dimensions 23.8
IP65 Stainless Resistive Panel PC Quick Start Guide 1.3.5 Dimensions 23.8” Unit: mm... -
Page 11: Physical Buttons And Led Indicators
Chapter 1: Introduction 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators located on the rear side of the Panel PC. Physical Buttons Icon Button Description Reset Press to reset the system Power On/ Off Press to power on or power off the device LED Indicators LED Type Status... -
Page 12: Wiring Requirements
IP65 Stainless Resistive Panel PC Quick Start Guide Chapter 2: Hardware Installation 2.1 Wiring Requirements The following safety precautions should be observed before installing any electronic device: • Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. -
Page 13: Serial Cable
Chapter 1: Introduction 2.2.2 Serial Cable The IP65 Stainless Resistive Panel PC has one waterproof serial port connector. Use serial cable to connect serial interfaces. 2.2.3 Ethernet Cable The IP65 Stainless Resistive Panel PC has one waterproof Ethernet connector. Use Ethernet cable to connect the Panel PC to the Internet. -
Page 14: Usb 2.0 Cable
2.3.1 VESA Mount The Panel PC has VESA mount holes on the rear side. Follow instructions below to mount the unit with VESA Mount bracket (not supplied by Winmate). Size VESA Plate... -
Page 15: Yoke Mount
Chapter 1: Introduction 2.3.2 Yoke Mount Yoke Mount solution allows installing the Panel PC with the bracket (not supplied by Winmate). Mounting instruction: 1. Place the Panel PC on the bracket stand, aiming screw holes for each other. 2. Secure screws to fix the device upon the bracket stand. -
Page 16: Chapter 3: Getting Started
IP65 Stainless Resistive Panel PC Quick Start Guide Chapter 3: Getting Started 3.1 Turning On and Off Your Device To turn on your device: 1. Connect the AC adapter to the DC-in jack connector located on the back side of the Panel PC. -
Page 17: How To Enable Watchdog
3.2 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details. -
Page 18: Appendix
IP65 Stainless Resistive Panel PC Quick Start Guide Appendix Appendix A: Hardware Specifications Model Name R15IW3S-65C3 R17IW3S-65M1 R19IW3S-65M1 W22IW3S-65A3 W24IW3S-65A2 Display 15” 17” 19” 21.5” Size 23.8” Resolution 1024 x 768 1280 x 1024 1280 x 1024 1920 x 1080... - Page 19 Appendix Model Name R15IW3S-65C3 R17IW3S-65A1 R19IW3S-65M1 W22IW3S-65A3 W24IW3S-65A2 Interfaces 1 x Waterproof 1 x Waterproof 1 x Waterproof 1 x Waterproof 1 x Waterproof Ethernet LAN Giga LAN RJ45 Giga LAN RJ45 Giga LAN RJ45 Giga LAN RJ45 Giga LAN RJ45...
-
Page 20: Appendix B: Winmate Software Development Kit
IP65 Stainless Resistive Panel PC Quick Start Guide Appendix B: Winmate Software Development Kit Winmate provides the following SDK and Utilities for the IP65 Stainless Resistive Panel PC. Item File Type Description Watchdog SDK Utility Watchdog Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. -
Page 21: Appendix C: Cleaning The Monitor
Appendix Appendix C: Cleaning the Monitor Before cleaning: • Make sure the device is turned off. • Disconnect the power cable from any AC outlet. When cleaning: • Use water up to 80°C to clean the housing. • Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. •... - Page 22 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
