7"/ 10.1"/ 15"
S Series HMI
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
Model No. W07IB3S-PCO1-POE
W07IB3S-PCO1AC-POE
W10IB3S-PCH2-POE
W10IB3S-PCH2AC-POE
W10IB3S-PCH2LB
R15IB3S-PCC3-POE
User Manual
Document Version 1.4
Document Part No. 9152111I1141
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W10IB3S-PCH2-POE and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate W10IB3S-PCH2-POE

Summary of Contents for Winmate W10IB3S-PCH2-POE

  • Page 1 7”/ 10.1”/ 15” S Series HMI Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Model No. W07IB3S-PCO1-POE W07IB3S-PCO1AC-POE W10IB3S-PCH2-POE W10IB3S-PCH2AC-POE W10IB3S-PCH2LB R15IB3S-PCC3-POE User Manual Document Version 1.4 Document Part No. 9152111I1141 Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    7~15" S Series HMI User Manual Contents Preface ..........................5 About This User Manual ..................... 9 Chapter 1: Introduction ....................10 1.1 Introduction ......................11 1.2 Product Features ....................11 1.3 Package Contents ....................12 1.4 Mechanical Dimensions ..................13 1.5 Physical Buttons and LED Indicators ..............
  • Page 3 Preface 4.2.4 Volume ..................... 36 4.2.5 LED Light Bar ................... 36 4.2.6 Performance ..................... 37 4.2.7 Touch Lock ....................37 4.3 Using HF RFID Reader ..................37 4.3.1 HF RFID Reader Location ................ 37 4.3.2 Trigger Setting ..................38 4.3.3 Settings..................... 39 4.3.4 RFID Output Settings................
  • Page 4 7~15" S Series HMI User Manual 7.2 Problem Report Form ..................- 84 - Appendix..........................85 Appendix A: Product Specifications................85 Appendix B: HF RFID Reader Specifications ............86 Appendix C: LED Light Bar Adjustment ..............87 Appendix D: Changing Screen Resolution ............... 89...

  • Page 5: Preface

    Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 6 7~15" S Series HMI User Manual Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
  • Page 7 Preface be easily accessible. • Keep this equipment away from humidity. • Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. • The openings on the enclosure are for air convection and to protect the equipment from overheating.
  • Page 8 7~15" S Series HMI User Manual • If the battery is placed elsewhere in equipment, there shall be a marking close to the battery or a statement in the servicing instructions. These marking or statement shall include the following or similar text: Caution Risk of explosion if battery is replaced by an incorrect type.

  • Page 9: About This User Manual

    About This User Manual About This User Manual This User Manual provides information about using the Winmate® Series HMI. This User Manual applies to the S Series HMI. The documentation set for the S Series HMI with Intel® Celeron® Bay Trail-M N2930 processors provides information for specific user needs, and includes: •...

  • Page 10: Chapter 1: Introduction

    7~15" S Series HMI User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter.

  • Page 11: Introduction

    0BChapter 1: Introduction 1.1 Introduction Congratulations on purchasing Winmate® S Series HMI. Winmate multi-touch S Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. The device provides real time update for booking status and available schedule, or performs as a synchronous display in meetings.

  • Page 12: Package Contents

    7~15" S Series HMI User Manual 1.3 Package Contents Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &...

  • Page 13: Mechanical Dimensions

    0BChapter 1: Introduction 1.4 Mechanical Dimensions This section describes appearance, connectors’ layout and mechanical dimensions of S Series HMI. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information. 7-inch, W07IB3S-PCO1-POE/ W07IB3S-PCO1AC-POE Unit: mm Dimensions:189.4 x 145.4 x 36.1...
  • Page 14 7~15" S Series HMI User Manual 10.1-inch, W10IB3S-PCH2-POE/ W10IB3S-PCH2AC-POE Unit: mm Dimensions:263.48 x 172 x 35.7 ① ⑥ № Description № Description GPIO (Optional)* RJ-45 (LAN/ PoE)** ② ⑦ ③ ⑧ RJ-45 (LAN) 2MP Front Camera (Optional) ④ USB 2.0, USB 3.0 ⑨...
  • Page 15 0BChapter 1: Introduction 10.1-inch, W10IB3S-PCH2LB Unit: mm Dimensions:263.48 x 172 x 35.7 № Description № Description ① ⑤ RJ-45 (LAN) RJ-45 (LAN/ PoE)** ② ⑥ USB 2.0, USB 3.0 All-Around LED Status Light Bar ③ ⑦ RS-232/422/485 HF RFID Reader (Optional) ④...

  • Page 16: Physical Buttons And Led Indicators

    7~15" S Series HMI User Manual 15-inch, R15IB3S-PCC3-POE Unit: mm Dimensions:363.4 x 277 x 86 x 44.5 № Description № Description ① ⑥ RJ-45 (LAN) Digital I/O (Optional) ② ⑦ USB 3.0 x 1 , USB 2.0 x 1 HF RFID Reader (Optional) ③...

  • Page 17: Connector Description

    0BChapter 1: Introduction Physical Buttons Icon Button Description Reset Press to reset the system Press to power on or power off the Power On/ Off device LED Indicators LED Type Status Description Power is on Power is off Storage activity Blinking (Data is being read or written) System is idle...

  • Page 18: Chapter 2: Getting Started

    7~15" S Series HMI User Manual Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations.

  • Page 19: Powering On

    1BChapter 2: Getting Started 2.1 Powering On 2.1.1 AC Adapter Components • 3 Pin Terminal Block • Power Cord • AC Adapter to DC Jack Safety Precautions: • Do not use the adapter in a high moisture environment • Never touch the adapter with wet hands or foot •...

  • Page 20: Connecting The Power

    7~15" S Series HMI User Manual 2.1.3 Connecting the Power Installation Instruction: Connect a 3-pin terminal block to the HMI connector. Connect the other side of the terminal block to the AC adapter. Connect the AC adapter to the power cord. Plug in the power cord to a working AC wall outlet.

  • Page 21: Ethernet Connector

    1BChapter 2: Getting Started 2.2.2 Ethernet Connector The HMI device has one RJ45 10/100/1000 Mbps Ethernet interface (LAN)for connecting to the internet and one RJ45 10/100/1000 Mbps Ethernet interface (LAN or PoE based on your order). Pin assignment and connector description of RJ45 connector. Pin №...

  • Page 22: Gpio Connector

    7~15" S Series HMI User Manual 2.2.5 GPIO Connector Notice that GPIO is an optional connector and may not be present in your model. Pin № Signal Name Pin № Signal Name 2.3 Configuring Serial Port Setting Serial port COM1 can be configured for RS-232, RS-422 or RS-485.Jumpers are located on the motherboard.

  • Page 23: Turning On And Off The Device

    1BChapter 2: Getting Started The picture below shows RS-232/422/485 (J8/J9) jumper setting. Example: To makeRS-232 Settings, set the Jumper 8 Pin 1-2 to the SHORT position, and Jumper 9 Pin1-2, 4-5, 7-8, 10-11 to the SHORT position. 2.4 Turning On and Off the Device The unit is configured to Power ON when is connected to the power source.

  • Page 24: Chapter 3: Mounting

    7~15" S Series HMI User Manual Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages.

  • Page 25: Cable Mounting Considerations

    2BChapter 3: Mounting 3.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the HMI device. Refer to Chapter 2, section 2.1 for the cable installation instruction. Caution Observe all local installation requirements for connection cable type and protection level.

  • Page 26: Panel Mount

    7~15" S Series HMI User Manual 3.3.1 Panel Mount Panel mount mounting solutions is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout Screw 7”...

  • Page 27: Vesa Mount

    2BChapter 3: Mounting 3.3.2 VESA Mount 3.3.2.1 VESA Desk Stand PCVS-V1 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name PCVS-V1 Part No. 99KK00A0000E Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 28 7~15" S Series HMI User Manual 3.3.2.2 VESA Desk Stand LA-100 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part No. 9B0000000128 Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 29 2BChapter 3: Mounting 3.3.2.3 VESA Wall Mount Bracket LA-106 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name LA-106 Part No. 9B0000000412 Installation Instruction...
  • Page 30 7~15" S Series HMI User Manual Accessories Dimensions...

  • Page 31: Front Side Wall Mount

    2BChapter 3: Mounting 3.3.3 Front Side Wall Mount The Front Side Wall Mount is only available for 10.1” S Series HMI. You can purchase Front Side Wall Mount Bracket from Winmate. Model Name PCFW-V1 Part No. 99KK00A0000C Mounting Instruction 1. Cut a hole in the wall according to the cutout dimensions.
  • Page 32 7~15" S Series HMI User Manual Dimensions...

  • Page 33: Glass Wall Mount

    The Glass Wall Mounting is only available for 10.1” S Series HMI. The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory.

  • Page 34: Chapter 4: Operating The Device

    7~15" S Series HMI User Manual Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device.

  • Page 35: Operating System

    3BChapter 4: Operating the Device 4.1 Operating System S Series HMI support several versions of Windows OS: Windows 10 IoT, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7– WS7P. Important: The device is shipped with the OS System according to your order.

  • Page 36: Brightness

    7~15" S Series HMI User Manual 4.2.3 Brightness Tap Brightness button to show current brightness level. To reduce the brightness, drag by touch to the left. To enhance the brightness, drag by touch to the right. Tap Close to save the changes and exit the interface. 4.2.4 Volume Tap Volume button to show your current volume level.

  • Page 37: Performance

    3BChapter 4: Operating the Device 4.2.6 Performance User can adjust the performance level of the HMI device. There are four options available: • Extreme performance • Office Document • High performance • Power Saving 4.2.7 Touch Lock To LOCK touch screen, double-click the Hot Tab icon on the Windows desktop, and tap Touch Lock.

  • Page 38: Trigger Setting

    7~15" S Series HMI User Manual To scan the card, bring it close to the right bottom front side of device with RFID icon. Tap on the Disconnect button to stop the connection with built-in HF RFID reader. 4.3.2 Trigger Setting •...

  • Page 39: Settings

    3BChapter 4: Operating the Device • Single Scan User can also define the RFID Reader scanning as Single Scan. Under this setting, the RFID Reader will be triggered only when user click on “Send”. 4.3.3 Settings • Sound The Sound check box defines whether a beep sound will come with the data scanning. •...
  • Page 40 7~15" S Series HMI User Manual User can also tap on the Settings button for further details settings. Item Description Prefix User can type in this field to define the characters BEFORE the data scanned. Suffix User can type in this field to define the characters AFTER the data scanned.

  • Page 41: Rfid Output Settings

    3BChapter 4: Operating the Device 4.3.4 RFID Output Settings Select RFID Output Type The default setting for built-in HF RFID Reader is to Read UID. For some applications, user might need to read or write further block data; the drop-down menu under this section can do this change.
  • Page 42 7~15" S Series HMI User Manual The Camera Screen Item Description Tap to record videos Video Tap to capture photos Photo Tap to select the destination folder to save captured photos and videos, enable preview, and select picture Settings resolution and quality Tap to close the camera Close Capture Screen...

  • Page 43: Shooting Photos

    3BChapter 4: Operating the Device 4.4.2 Shooting Photos 1. Open the Camera. 2. Focus on the object. 3. Tap to capture the object. 4. By default, the photo preview is displayed briefly on the screen. The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen.

  • Page 44: Recording Videos

    7~15" S Series HMI User Manual 4.4.3 Recording Videos 1. Open the Camera. 2. Focus on the object. 3. Tap to record the video. The video recording screen appears. 4. Tap to stop recording and return to the camera screen. 5.

  • Page 45: Camera Settings

    3BChapter 4: Operating the Device 4.4.4 Camera Settings 1. Tap to open the setting page. 2. Modify necessary settings. Item Description Check one of the check boxes to show the preview screen right after capturing a photo. • Show Preview: Check this box and enter the preview duration on Close preview after.

  • Page 46: How To Enable Watchdog

    7~15" S Series HMI User Manual 4.5 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. Refer to Ch.7, “Technical Support”...

  • Page 47: Chapter 5: Bios Setup

    4BChapter 5: BIOS Setup Chapter 5: BIOS Setup BIOS Setup Utility is a program for configuration basic Input/ Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.

  • Page 48: When And How To Use Bios Setup

    7~15" S Series HMI User Manual 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>...

  • Page 49: Bios Settings

    4BChapter 5: BIOS Setup Note: You can press the F1, F2, F3, F4, –/+, and Esc keys by connecting a USB keyboard to your device. 5.3 BIOS Settings 5.3.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date.

  • Page 50: Advanced Menu

    7~15" S Series HMI User Manual 5.3.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. Important: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer.
  • Page 51 4BChapter 5: BIOS Setup BIOS Setting Description Setting Effect Option ACPI Settings Configures ACPI settings Enter Opens submenu F81866 Super IO Configures IO settings Enter Opens Configuration submenu Hardware Monitor Configures Hardware Monitor Enter Opens settings submenu S5 RTC Wake Settings Configures RTC Wake parameters Enter Opens...
  • Page 52 7~15" S Series HMI User Manual 5.3.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
  • Page 53 4BChapter 5: BIOS Setup 5.3.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen. For items marked with ►, please press <Enter>...
  • Page 54 7~15" S Series HMI User Manual Watch Dog Time Select You can either disable Watch Dog Timer or set up the time.Use <Arrow> keys to navigate and please press <Enter>to select the item. GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control.
  • Page 55 4BChapter 5: BIOS Setup 5.3.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. 5.3.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time.
  • Page 56 7~15" S Series HMI User Manual Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time. or example: If you want the system to start up automatically at 15:30:30, the 10th day of each month, then you should enter 10, 15, 30, and 30 from top to bottom.
  • Page 57 4BChapter 5: BIOS Setup 5.3.2.5 CPU Configuration BIOS Setting Description Setting Effect Option Socket CPU This item contains socket specific Enter Open sub-menu Information CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Maximum Disabled/E Enable/Disable Maximum nabled...
  • Page 58 7~15" S Series HMI User Manual 5.3.2.6 PPM Configuration BIOS Setting Description Setting Effect Option CPU C State Shows CPU C State Report Enabled/ Enable or Disable Report Disabled CPU C state report to Max CPU C- Allows to enter power-saving C1E, C3, Enable or Disable State...
  • Page 59 4BChapter 5: BIOS Setup 5.3.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Setting Description Setting Option Effect Critical Trip Point Specifies the 90C, 87C, 85C, 79C, Select the disable...
  • Page 60 7~15" S Series HMI User Manual 5.3.2.8 IDE Configuration...
  • Page 61 4BChapter 5: BIOS Setup BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this (SATA) supporting chipset drives Disabled function with SATA interface. SATA Speed Allows forcing the speed Gen1 The maximum speed will be Support limit SATA II ports limited to 150 MB/s...
  • Page 62 7~15" S Series HMI User Manual 5.3.2.9 Miscellaneous Configuration OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Option Effect Windows 8.X Allows user to choose the Enter Use Windows 8.X proper OS. Windows 7 Allows user to choose the Enter...
  • Page 63 4BChapter 5: BIOS Setup 5.3.2.10 CSM Configuration BIOS Setting Description Setting Effect Option CSM Support The Compatibility Support Module Enabled/ Enable or disable the is a component of the UEFI Disabled Compatibility Support firmware that provides legacy Module BIOS compatibility by emulating a BIOS environment, allowing legacy OS and some option ROMs that do not support UEFI to still be used.
  • Page 64 7~15" S Series HMI User Manual 5.3.2.11 USB Configuration...
  • Page 65 4BChapter 5: BIOS Setup BIOS Setting Description Setting Effect Option Legacy USB User can enable or disable USB Disable Will keep USB devices Support port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 User can enable or disable USB Enable Enable USB 3.0 is Support...
  • Page 66 7~15" S Series HMI User Manual 5.3.2.12 Security Configuration BIOS Setting Description Setting Effect Option Trusted Execution Technology Enabled/ Enables or disables parameters Disabled this function TXE HMRFPO TXE HMRFPO parameters Enabled/ Enables or disables Disabled this function TXE Firmware TXE Firmware Update Enabled/ Enables or disables...

  • Page 67: Chipset Menu

    4BChapter 5: BIOS Setup 5.3.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Timer Enabled/ Enables/Disable Precious settings Disabled s this function Timer Restore AC This function allows to set up booting...

  • Page 68: Security Menu

    7~15" S Series HMI User Manual 5.3.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has been password set.

  • Page 69: Boot Configuration

    4BChapter 5: BIOS Setup 5.3.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system.The bootable devices will be automatically detected during POST and shown here,allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.
  • Page 70 7~15" S Series HMI User Manual BIOS Setting Description Setting Effect Option Setup Prompt Allows user to configure the number Enter Set the prompt Timeout of seconds to stay in BIOS setup timeout prompt screen. Boot NumLock Enables or disables NumLock feature Remains On State on the numeric keypad of the...

  • Page 71: Save& Exit

    4BChapter 5: BIOS Setup 5.3.6 Save& Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied.
  • Page 72 7~15" S Series HMI User Manual BIOS Setting Description Setting Effect Option Save This saves the changes to the Enter Save changes Changes and CMOS and exits the BIOS Setup <YES> Exit program. Discard This exits the BIOS Setup without Enter Saves the changes Changes and...

  • Page 73: Using Recovery Wizard To Restore Computer

    4BChapter 5: BIOS Setup 5.4 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: • Plug-in the AC adapter to Bay Trail series computer. Make sure the computer stays plugged in to power source during the recovery process.

  • Page 74: Chapter 6: Driver Installation

    7~15" S Series HMI User Manual Chapter 6: Driver Installation This chapter describes how to install all necessary drivers.

  • Page 75: Installing Chipset Driver

    5BChapter 6: Driver Installation 6.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue.
  • Page 76 7~15" S Series HMI User Manual Step 3 Click Yes to agree the license terms. Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation.

  • Page 77: Installing Graphics Driver

    5BChapter 6: Driver Installation 6.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 78: Installing Intel Sideband Fabric Device (Intel Mbi) Driver

    7~15" S Series HMI User Manual 6.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver Only for Windows 8.1. Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation.

  • Page 79: Installing Intel Trusted Engine Interface (Intel Txe) Driver

    5BChapter 6: Driver Installation 6.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 80: Installing Intel Network Connections

    7~15" S Series HMI User Manual 6.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver.

  • Page 81: Installing Audio Driver

    5BChapter 6: Driver Installation 6.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.

  • Page 82: Installing Usb 3.0 Driver

    7~15" S Series HMI User Manual 6.7 Installing USB 3.0 Driver Only for Windows 7. Note: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. This HMI features Intel Celeron Trail-M N2930CPU with the Intel®...

  • Page 83: Chapter 7: Technical Support

    6BChapter 7: Technical Support Chapter 7: Technical Support This chapter includes the directory for technical support. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products.

  • Page 84: Introduction

    7.1 Introduction To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center. Winmate provides the following Drivers for S Series HMI:...

  • Page 85: Appendix

    Appendix Appendix Appendix A: Product Specifications Model Name W07IB3S- W07IB3S- W10IB3S- W10IB3S- W10IB3S- R15IB3S- PCO1-POE PCO1AC-POE PCH2-POE PCH2AC-POE PCH2LB PCC3-POE Display 10.1" TFT Size/ Type 7" TFT (Wide) 7" TFT (Wide) 10.1" TFT (Wide) 10.1" TFT (Wide) 15" (Wide) Resolution 1024 x 600 1024 x 600 1280 x 800...

  • Page 86: Appendix B: Hf Rfid Reader Specifications

    7~15" S Series HMI User Manual Model Name W07IB3S- W07IB3S- W10IB3S- W10IB3S- W10IB3S- R15IB3S- PCO1-POE PCO1AC-POE PCH2-POE PCH2AC- PCH2LB PCC3-POE Input / Output Connectors 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal Power block block block block block block...

  • Page 87: Appendix C: Led Light Bar Adjustment

    Appendix Appendix C: LED Light Bar Adjustment Note: PoE Hub requires the power of more than 25 Watt. This section describes how to adjust LED Light Bar with RS-232 settings. Baud Rate 9600 Data Bits Parity: None Stop Bits Reading Version NO.
  • Page 88 7~15" S Series HMI User Manual Reply Value : 3 C F1 Set Success 3 B F2 Not Success *1: Checksum is 2’s complement of sum of length and all messages. Setting Function NO. Function Length Command index Value Checksum(*1) Supplement Load Default 0x05 0x40 0x21...

  • Page 89: Appendix D: Changing Screen Resolution

    Appendix Appendix D: Changing Screen Resolution If you plug HDMI cable from this device to an external display, touch resolution will be influenced by the external display. Follow instructions below how to adjust touch resolution. 1. Right-click mouse on the desktop, select Display Settings. 2.
  • Page 90 7~15" S Series HMI User Manual 3. Whether to keep the display settings message appears, click Keep changes. 4. Right-click on the Windows icon and select Control Panel. 5. Select Tablet PC Settings.
  • Page 91 Appendix 6. Select Setup, the window will jump out Touch this screen to identify it as the touchscreen, click the Touch and press ok.
  • Page 92 7~15" S Series HMI User Manual 7. Go back to Display settings again, Extend these displays have been changed to Duplicate these displays, click Apply.
  • Page 93 Appendix 8. Select Keep changes.
  • Page 94 Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
  • Page 95 Notes ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
  • Page 96 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
