UC912G IP Phone

Checking the Contacts using the Phone interface

Press Directory→ Left Button→ Left Button, and then you can see the item you set, press enter and
you will find the detail.
Remote contact lists only support up to 1000 contacts

LDAP Phonebook

When use the LDAP, you can get the LDAP Phonebook directly.

Configuring LDAP using the web interface

1. Login to the web interface (refer to
Directory→ LDAP
2. Enter the LDAP Name Filter
a. This parameter specifies the name attributes for LDAP searching. The "%" symbol in
the filter stands for the entering string used as the prefix of the filter condition.
b. For example (cn=%), when the name prefix of the cn of the contact record matches
the search criteria, the record will be displayed on the IP PHONE LCD.
3. Enter LDAP Number Filter:
a. This parameter specifies the number attributes for LDAP searching.
4. Enter Server Address: enter the domain name or IP address of the LDAP Server, for example:
192.168.0.124
5. Enter Port (the port of the LDAP Server), Base, User Name, and Password
6. Enter Max.Hits (1-32000): the maximum number of the search results to be returned by the
LDAP server.
7. Enter LDAP Display Name: the display name of the contact record displayed on the LCD
screen.
8. Enter the relative value and then click SaveSet to save the settings.
Following is an example of the screenshot for the configuration.
Copyright © 2019 Xorcom Ltd.
Web Login for details of the login process) and click
