Two Fuses on One String via Y Adapter
Figure 4: Two fuses on one string via Y adapter (example)
Connection of Pre-Fabricated Cable Harnesses with Integrated String Fuse
Figure 5: Connection of pre-fabricated cable harnesses with integrated string fuse (example)
Position
A
B
C
D
E
F
G
Technical Information
Designation
PV module
DC connector (positive terminal)
Inline fuse connector
DC connector (negative terminal)
Y adapter
Integrated string fuse
SMA String-Monitor
