SMA STRING-MONITOR SSM-U-2410 Technical Information page 20

7 Technical Data
Connection Functional Grounding to DC Surge Arrester
Sealing range of cable gland
Recommended cable type
Connection Functional Grounding to Electronic Assembly
Terminal
Conductor cross-section for surge arrester type 2
Cable gland
Sealing range of cable gland
Recommended cable type
Interfaces for Temperature Measurement
Number (module/ambient temperature)
Plug-in temperature sensor
Measurement range
Maximum error at +25°C*
Maximum error in temperature range*
Terminal
Conductor cross-section
Cable gland
Sealing range of cable gland
* based on the measurement range end value (with four-wire measurement)
Digital Input (Customer)
Quantity
Supply voltage
Maximum output current (for sensors)
Switching threshold, low level
Switching threshold high level
Nominal input voltage
Nominal input current
Terminal
20 SSMUXX1015-TI-en-10
5.0 mm to 10.2 mm
NYY-O
Spring-cage terminal with actuation lever on the
electronic assembly
6 mm
Multiple feed-through
5.0 mm to 10.2 mm
NYY-O
PT100 and PT1000 with two-, three- and four-wire
measurement
−40°C to +100°C
±0.5%
±2.0%
Spring-cage terminal with actuation lever on the
electronic assembly
2
0.08 mm to 1.00 mm
Multiple feed-through
3.2 mm to 6.5 mm
24 V
DC
150 mA
V
LMAX
V
HMIN
24 V
5 mA
Spring-cage terminal with actuation lever on the
electronic assembly
SMA Solar Technology AG
2
2
2
1
±20%
3 V
15 V
DC
Technical Information
