7 Technical Data
Digital Output
Minimum electrical endurance when the maximum switch-
ing voltage and maximum switching current are complied
with
Terminal
Conductor cross-section
Cable gland
Sealing range of cable gland
Data Transmission Copper Wire
Data interface
Local area network (LAN)
Connection without surge arrester
Connection with surge arrester*
Recommended cable type
Maximum cable length
Cable gland
Sealing range of cable gland
* available as an accessory (see Section 8, page 24)
Data Transmission Optical Fiber*
Data interface
Local area network (LAN)
Direct connection multimode optical fiber cable to optical
fiber Piggy-Back**
Fiber type
Fiber grade
Connection multimode optical fiber cable to splice box
***
Cable gland
Sealing range of cable gland
* Accessory optical fiber Piggy-Back required OF Piggy-Back accessories required (see Section 8, page 24)
** available as an accessory (see Section 8, page 24)
*** available as an accessory (see Section 8, page 24); optical fiber pigtail is not included in the accessory scope of delivery
Ambient Conditions
Standard operating temperature range
22 SSMUXX1015-TI-en-10
SMA Solar Technology AG
1,000,000 switching cycles
Spring-cage terminal with actuation lever on the
electronic assembly
2
0.5 mm to 6.0 mm
Multiple feed-through
3.2 mm to 6.5 mm / 5.0 mm to 10.2 mm
Modbus (TCP)
Ethernet
LSA+
RJ45
Cat5 cable with shielding S-UTP, F-UTP or higher
100 m
Multiple feed-through
3.2 mm to 6.5 mm / 5.0 mm to 10.2 mm
Modbus (TCP)
Ethernet
SC coupling
Multimode 50.0/125.0 µm or 62.5/125.0 µm
OM1 or higher
Splicing/optical fiber pigtail SC multimode
Multiple feed-through
3.2 mm to 6.5 mm / 5.0 mm to 10.2 mm
‒40°C to +50°C
