Technical Data - SMA STRING-MONITOR SSM-U-2410 Technical Information

SMA Solar Technology AG

7 Technical Data

Enclosure
Outdoor installation
Material
Combustion properties
IP degree of protection in accordance with IEC 60529
IK degree of protection in accordance with IEC 62262
Protection class in accordance with IEC 60529
Pollution degree in accordance with IEC 61010-1
Color
UV resistance in accordance with IEC 61439-1
Wall mounting
Pole mounting*
Lock cylinder
Cable support rail**
* available as an accessory (see Section 8, page 24)
** to be provided by the customer
Mechanical Data
Enclosure width
Enclosure with including vent plug
Enclosure height including wall bracket lugs
Enclosure height including string cable harness
Enclosure depth
Enclosure depth including wall bracket lugs
Enclosure depth including wall bracket lugs and pole
mounting bracket*
Maximum weight**
Weight of pole mounting bracket*
Minimum clearance between enclosure and floor if inline
fuse connectors are installed underneath the SMA String-
Monitor
* available as an accessory (see Section 8, page 24)
** depending on the number of string inputs of the SMA String-Monitor, without accessories
Electrical Data
PV array
Technical Information
Shaded
Glass-fiber reinforced plastic
Self-extinguishing, halogen-free
IP54
IK10
RAL 7035
Double-bit key for switch cabinet
600 mm
630 mm
850 mm
1,055 mm
300 mm
320 mm
385 mm
34 kg
2.1 kg
800 mm
Negatively grounded/positively grounded/insulated
SSMUXX1015-TI-en-10
7 Technical Data
II
2
Yes
Yes
Yes
Yes
17
