Table 2: Termination Details
Type of Field Device
Temperature Sensor
Voltage Input - External
Source
Voltage Input - Internal
Source
Voltage Input
(Self-Powered)
Current Input - External
Source (Isolated)
Current Input - Internal
Source (2-wire)
FEC1611 and FEC1621 Field Equipment Controller Installation Instructions
Type of
Termination Diagrams
Input/Output
UI
UI
UI
UI
UI
UI
10
