INSTALLATION
Straight Pipe Recommendations
Reduced Pipe
Two Elbows In Plane
Two Elbows, Out Of Plane
Expanded Pipe
Spiral Flow
Swirling Flow
Seametrics • 253.872.0284
(X = diameter)
Propeller Meter
Partially Open
Butterfly Valve
10X
5X
10X
5X
20X
5X
20X
5X
30X
20X
Page 9
IP100/200 SERIES INSTRUCTIONS
seametrics.com
