Ft440; Ft450 - Seametrics IP100 Series Instructions Manual

CONNECTIONS

FT440

+
4-20mA
_
Device
9-30 Vdc
_
+
Loop Power
Supply
Flow
Sensor

FT450

BLACK
WHITE
RED
Micropower
Flow Sensor
Seametrics • 253.872.0284
_
_
+
+
BLACK
_
_
WHITE
S
RED
+
+
FT450
Lithium C,
3Vdc
_
+ Replaceable
Battery
_
_
S
+
+
FT440
_ _
+
+
_
_
+
+
_ _
+
+
_
_
+
+
Page 12
IP100/200 SERIES INSTRUCTIONS
Electronic
Metering Pumps
Pulse
Pass-thru
Pulse Responsive
Metering Pump
Current Sinking
Polarity-Sensitive
