- Page 1 IP100/200 Series Adjustable Depth Insertion Paddlewheel Instructions IP11x/21x (Shown with externally powered electronics) IP15x/25x (Shown with battery powered electronics) PROUDLY MADE IN THE 9001:2008...
-
Page 2: Table Of Contents
Calibration (K-Factor) ..............................Page 13 Rotor Replacement ..............................Page 13 Checking Signal ................................Page 13 Parts Explosion ................................Page 14 Parts List ..................................Page 14 Troubleshooting Problem ...................................Page 15 Probable Cause ................................Page 15 Things To Try..................................Page 15 Warranty Seametrics Limited Warranty ..........................Back Seametrics • 253.872.0284 Page 2 seametrics.com... -
Page 3: General Information
4-20 mA analog output. The AO55 is a be purchased either locally or from Seametrics. blind analog (4-20 mA) transmitter. Programmable pulse Ruby bearings and a non-drag Hall-effect sensor give these... -
Page 4: Specifications
See meter mounted electronic specification for rating. Environmental Regulatory Mark *Specifications subject to change. Please consult our website for the most current data (www.seametrics.com). Kynar is a registered trademark of Arkema, Inc. Seametrics • 253.872.0284 Page 4 seametrics.com... -
Page 5: Installation
Bottom (6 o’clock), top (12 o’clock), and vertical pipe installations are all acceptable if required by the piping layout. Fair Unacceptable if pipe contains air Best Position Fair Unacceptable if pipe contains sediment Orienting the Meter Seametrics • 253.872.0284 Page 5 seametrics.com... -
Page 6: Ip11X/21X Installation
When the sensor is secure, open the valve and adjust depth setting (see diagram and instructions that follow). Be sure flow is in the direction of the arrow on the housing. Tighten locking collar and compression nut fully. Seametrics • 253.872.0284 Page 6 seametrics.com... -
Page 7: Depth Setting
Depth Setting It is important for accuracy that the sensor be inserted to the correct depth into the pipe. 1. Go to www.seametrics.com and select the K-factor “D” Calculator located at the bottom of the home page to find dimension D (insertion depth setting)*. -
Page 8: Pipe Wall Thickness
12530 29140 35350 56400 20.0 1250 1800 3120 4920 6980 11020 25060 58270 70700 112800 30.0 1190 1870 2700 4680 7370 10470 16520 37600 87410 106050 170000 * Call factory for larger pipe sizes. Seametrics • 253.872.0284 Page 8 seametrics.com... -
Page 9: Straight Pipe Recommendations
INSTALLATION IP100/200 SERIES INSTRUCTIONS Straight Pipe Recommendations (X = diameter) Reduced Pipe Two Elbows In Plane Two Elbows, Out Of Plane Expanded Pipe Spiral Flow Propeller Meter Swirling Flow Partially Open Butterfly Valve Seametrics • 253.872.0284 Page 9 seametrics.com... -
Page 10: Full Pipe Recommendations
Allows air to bleed off Caution: These flow sensors are not recommended for installation downstream of a boiler feedwater pump where installation fault may expose the flow sensor to boiler pressure and temperature. Maximum recommended temperature is 200°F. Seametrics • 253.872.0284 Page 10 seametrics.com... -
Page 11: Connections
RED (+) 6-24 Vdc Micropowered: 3.1 - 16 Vdc WHITE WHITE (signal) Signal BLACK (-) BLACK (-) Power Power 18' cable standard FT430 FT430 Pulse Pass-thru 7-45Vdc Supply BLACK WHITE Pulse Responsive Metering Pump Flow Sensor Seametrics • 253.872.0284 Page 11 seametrics.com... -
Page 12: Ft440
Device 9-30 Vdc Loop Power Supply BLACK WHITE Electronic Metering Pumps Flow Sensor FT450 FT450 Pulse Pass-thru Lithium C, 3Vdc Replaceable Battery BLACK WHITE Pulse Responsive Metering Pump Current Sinking Micropower Polarity-Sensitive Flow Sensor Seametrics • 253.872.0284 Page 12 seametrics.com... -
Page 13: Operation And Maintenance
It is normally provided Checking Signal for Seametrics sensors in pulses per gallon, and is given on the chart “K-factors for Various Pipe Sizes.” These The flow sensor has only one moving part, the rotor. -
Page 14: Parts Explosion
100116 (ss) Adapter fitting O-ring 100345 (EPDM) Adapter, hot tap 100384 (brass) 100385 (ss) Nipple, 2 inch 100066 (brass) 100103 (ss) Valve assembly 100069 (brass) (includes valve plus B, 100119 (ss) C, & D above) Seametrics • 253.872.0284 Page 14 seametrics.com... -
Page 15: Troubleshooting
Refer to installation recommendations (see pages 5 - 10) Fluctuating around low flow cutoff Check velocity vs. pipe size (see page 8) Not enought straight pipe Refer to installation recommendations (see pages 5 and 9) Seametrics • 253.872.0284 Page 15 seametrics.com... - Page 16 SEAMETRICS LIMITED WARRANTY IP100/200 SERIES INSTRUCTIONS The limited warranty set forth below is given by Seametrics, with respect to Seametrics and INW brand products purchased in the United States of America. Seametrics warrants that products manufactured by Seametrics, when delivered to you in new condition in their original containers and properly installed, shall be free from defects in material and workmanship.
