INSTALLATION
Straight Pipe Recommendations (X = diameter)
Reduced Pipe
Two Elbows In Plane
Two Elbows, Out Of Plane
Expanded Pipe
Spiral Flow
Swirling Flow
Seametrics • 253.872.0284
Propeller Meter
Partially Open
Butterfly Valve
10X
5X
15X
5X
20X
5X
20X
5X
30X
50X
Page 6
EX800 - SERIES INSTRUCTIONS
