Hardware

VLT control card terminals

The terminals on the control card are allocated for positioning controller functions the following
parameter settings should therefore not be changed in positioning mode (set-up 1):
Digital inputs 16, 17, 18, 19, 27, 29, 32 and 33
Parameters 300–303 and 305–307 are set to "No operation" (default setting), then the inputs are
ignored by the control card but used as inputs to the positioning controller.
Analogue inputs 53, 54 and 60
Parameters 308, 311 and 314 are set to "No operation", then the inputs are ignored by the control card
but used as inputs to the positioning controller.
Digital/analogue outputs 42 and 45 (VLT 5000)
Parameters 319 and 321 are set to:
OPTION 0 ... 20 mA [91]
Digital outputs 26 and 46 - Analogue outputs 42 and 45(VLT 5000 Flux)
Parameters 319 and 321 are set to:
OPTION 0 ... 20 mA [90]
Parameters 341 and 355 are set to:
OPTION digital

Technical data

Technical data on the control card terminals can be found in the VLT 5000 design guide.

Option card terminals

There are two encoder interfaces, which are covering the following functions:
• Primary Feedback encoder input
• Secondary encoder input
There are 8 digital inputs, 8 digital output and terminals for 5 V and 24 V supply. The functions and
technical data of the terminals are described in the following.
Terminal
Incremental input
Absolute input
Fig. 1
Terminal
Incremental input
Absolute input
Fig. 2
MG.50.P3.02 - VLT is a registered Danfoss trademark
Positioning Controller
analogue output
(default setting)
analogue output
(default setting)
[90] digital output
(default setting)
A1 A1
A in A in
Clk out Clk out
A2 A2
A in A in
Clk out Clk out
B1 B1 Z1
B in B in Z in
Data in Data in Not used
B2 B1 Z2
B in B in Z in
Data in Data in Not used
Z1
Z in
Not used
Z2
Z in
Not used
5
