No. Parameter
713 Encoder type
ENCODER TYPE
714 Encoder resolution
ENCODER RES.
715 Automatic brake
control
AUTO. BRAKE
CTRL
24
Positioning Controller
Default Range
value
0 0 = incremental
1 = absolute
260kHz clock
2 = absolute
105kHz clock
3 = absolute
260kHz clock
& error
correction
4 = absolute
105kHz clock
& error
correction)/
+100 enable
hardware
encoder
monitor.
4.096 ps. 1 ... 1,000,000
pulses
1 0 = disabled
1 = enabled
Description
It is possible to use two types of encoder. If
you select any absolute encoder the home
flag is instantly set high, thus no homing is
required preceding a positioning
command.
Type 3 and 4 are to be used for linear
absolute encoder. A possible leap in the
position data can be detected if it is larger
than the encoder resolution/2. The correc-
tion is made by means of an artificial
position value which is calculated from the
last velocity. If the error continues for more
than 100 read-outs (> 100 ms), there will
be no further correction which will then
lead to a tolerated position error exceeded.
Type 3 and 4 are only available if encoder
feedback is via MK 3 D (see description of
parameter 748) type.
100 ... 104 = like 0 ... 4, however, hard-
ware monitoring of the encoder will be
activated. Error 92 will be issued in case of
open or short circuit.
NB! When switching from a setting of ab-
solute encoder to a setting of incremental
encoder, the home flag is automatically
cleared. A homing procedure afterwards is
necessary before any positioning com-
mands can be executed.
The encoder resolution must be entered in
pulses per revolution (not quad-counts per
revolution).
When the automatic brake control function
is enabled, the electromechanical brake is
automatically activated every time the
application has been at standstill for a time
period specified in parameter 718. This is
especially useful in hoist applications
where the motor could overheat if it has to
deliver full torque at standstill for a pro-
longed period of time.
When the automatic brake control function
is disabled, the drive controls the applica-
tion also at standstill.
