— Front Head Assembly

9.16 — Front Head Assembly
9.16.1 — 55" & 60"
Item
Qty
Description
1
1
Inner Door Plate Assembly
2
1
Bulk Plate
3
1
Blower Inlet Windbox
4
1
Front Head
5
9
Lug
6
1
Blower Pedestal Assembly
7
2
Front Head Support
8
1
Housing to Head Gasket
9
1
Blanket Insulation
10
1
Screen
11
150oz
Coating Cement Rigidizer
12
1
Plate
13
1
Front Door Hinge
14
2
Gusset
15
1
Front Head Interior Insulation
750-368
CBEX Elite 100-1200 HP
55"
60"
Part #
Part #
132-02731
132-02702
972-00002
972-00002
039-01740
039-01736
132-02730
132-02704
103-00097
103-00097
085-04050
085-03140
085-01542
085-01542
032-03175
032-03171
872-01084
872-01084
930-00135
930-00135
872-00443
872-00443
077-02126
077-02126
462-00183
462-00183
059-09727
059-00805
465-02731
465-01675
9-19
