— Main Gas Train

9.3 — Main Gas Train
Item Qty Description
6 1 LGPS
7 1 HGPS
22 1 Alum. Tubing
23 2 Butterball Valve
24 2 Ball Valve
25 1 Actuator w/POC
26 1 Actuator w/o POC
27 1 Gas Valve Body
Item Qty Description
6 1 LGPS
23 2 LUB Plug Valve
24 1 Ball Valve
750-368
CBEX Elite 100-1200 HP
100-125 150-200
817-02416 817-02416
817-02420 817-02420
939-00642 939-00642
941-01946 941-01946
* 941-02640
945-00234 945-00234
X 945-00238
949-00461 949-00447
100-125 350-400
941-02640 941-02640
250-300 350-400
817-02418 817-02418
817-02417 817-02417
939-00642 939-00642
941-01947 941-01947
941-02640 *
945-00234 945-00234
945-00238 945-00238
949-00448 949-00448
500HP 600HP
817-02418 817-03591
941-00129 941-00130
941-02640 941-02640
500-600 700-800
* 817-03591
817-02423 817-02423
939-00642 939-00642
* *
* *
945-00234 945-00234
945-00238 945-00238
949-00445 949-00446
700-800
941-00130
941-02640
