9.16.4 — 85" & 92"
Item Qty Description
1 1 Inner Door Plate Assembly
2 1 Front Head Ring
3 1 Air Duct Assembly
4 1 Front Head
5 13 Lug
6 1 Davit Support
7 2 Flat Bar
8 1 Head Plate Gasket
9 1 Blanket Insulation
10 1 Screen
11 1 Interior Insulation
Assembly No.
85" 132-02675 (RH)
85" 132-02736 (RH)
92" 132-02694 (RH)
92" 132-02744 (RH)
9-22
85"
Part #
See Table
080-00935
039-01727
132-02677
103-00107
085-03119
971-00078
032-00993
872-01084
930-00135
See Table
IFGR Plate Item #1
30 ppm 132-02674
60 ppm 132-02674
30 ppm 132-02695
60 ppm 132-02695
92"
Part #
See Table
080-01330
039-01732
132-02696
103-00107
085-03119
971-00078
032-00993
872-01084
930-00135
See Table
Item #11
465-02366
N/A
465-02655
N/A
Parts
750-368
CBEX Elite 100-1200 HP
