3.2 — Water Requirements
NOTE: The circulating pumps should be interlocked with the burner so that the burner cannot operate unless the cir-
culating pump is running in order to avoid damage to the equipment.
Water Circulation
The Maximum Circulating Rate Chart, Figure 3-2, shows the maximum gpm circulation rate of boiler water in
relation to full boiler output and system temperature drop.
Boiler Output
BHP MBTU/hr
100 3,350
125 4,185
150 5,025
200 6,695
250 8,370
300 10,045
350 11,720
400 13,400
500 16,740
600
20,080
700 23,430
800 26,780
Maximum Circulating Rate Chart
FIGURE 3-2.
Multiple Boiler Installations
When multiple boilers are used, care must be taken to ensure adequate or proportional flow through the boilers.
Proportional flow can best be accomplished by use of balancing valves and gauges in the supply line from each
boiler. If balancing valves or orifice plates are used, a significant pressure drop (e.g., 3-5 psi) must be taken
across the balancing device to accomplish the purpose.
If care is not taken to ensure adequate or proportional flow through the boilers, wide variations in firing rates
between the boilers can result.
In extreme cases, one boiler may be in the high-fire position while the other boiler or boilers may be at low fire.
The net result would be that the common header water temperature to the system would not be up to the desired
point.
Pump Location
It is recommended that the system circulating pumps take suction from the outlet connection on the boiler, and
that they discharge to the system load. The suction side is preferred because it decreases air entry into the sys-
tem and does not impose the system head on the boiler.
