— Front Head Assembly
9.16.3 — 78"
Item Qty Description
1 1 Inner Door Plate Assembly
2 1 Front Head Ring
3 1 Air Duct Assembly
4 1 Front Head
5 13 Lug
6 1 Davit Support
7 2 Flat Bar
8 1 Head Plate Gasket
9 1 Blanket Insulation
10 1 Screen
11 1 Interior Insulation
12 180oz Coating Cement Rigidizer
Assembly No. IFGR Plate
132-02683 (RH) 30 ppm
132-02740 (RH) 60 ppm
750-368
CBEX Elite 100-1200 HP
78"
Part #
See Table
080-01460
039-01730
132-02684
103-00107
085-03125
971-00078
032-00898
872-01084
930-00135
See Table
872-00443
Item #1 Item #11
132-02682 465-01680
132-02682 N/A
9-21
