Wiring diagrams> Internal wiring
Wiring diagram
Ä Antenna configura-
tions
3.4.1 Internal wiring
The following table provides an overview of the internal wiring diagrams that are
described in the following chapters.
Overview of internal wiring diagrams
Wiring diagram
Ä Internal wiring with four CHUs and
DUPLEXER
Ä Internal wiring with four CHUs and TX
FILTER
3.4.1.1
Internal wiring with four CHUs and DUPLEXER
The following figure shows the internal wiring with four CHUs and DUPLEXER.
56
Ä Antenna configuration with four
CHUs and DUPLEXER
Ä Antenna configuration with four
CHUs and TX FILTER
Described in
Ä Chapter 3.4.1.1 "Internal wiring with four
CHUs and DUPLEXER" on page 56
Ä Chapter 3.4.1.2 "Internal wiring with four
CHUs and TX FILTER" on page 57
Operation Manual 90DIBR5advancedOM02 - 1.0
DIB-R5 advanced
Described in
Ä Antenna configura-
tion with four CHUs and
DUPLEXER
Ä Chapter 3.4.3.2
"Antenna configuration
with four CHUs and TX
FILTER" on page 59
