Components> VDC voltage supply
Figure 14: DPDM (top view)
Legend: DPDM (top view)
No.
1
2
3
The following figure shows the front view of the DPDM. The following table describes it in
detail.
36
Component
Surge protection
On/off switch
Terminals
Description
Surge Protection Device (SPD) of the
DIB-R5 advanced
On/off switch of the DIB-R5 advanced
Terminals for V
DC
Operation Manual 90DIBR5advancedOM02 - 1.0
DIB-R5 advanced
input voltage
