Body Worn Camera
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM550D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hytera VM550D

Summary of Contents for Hytera VM550D

  • Page 1 Body Worn Camera USER MANUAL...
  • Page 2 Preface Welcome to the world of Hytera and thank you for purchasing this product. To derive optimum performance from the product, please carefully read this manual before use. This manual is applicable to the following product: VM550D Body Worn Camera (with Wi-Fi)

  • Page 3: Icon Conventions

    Indicates situations that could cause minor personal injury. Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.

  • Page 4: Fcc Statement

    2006/66/EC  2011/65/EU  2012/19/EU  2014/53/EU  Please note that the above information is applicable to EU countries only. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Body-Worn Operation

    This product meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
  • Page 6 The device complies with RF specifications when the device used at 5 mm form your body. Hereby, Hytera Communications Corporation Limited declares that this product is in compliance with essential requirements and other relevant provisions of Directive 2014/53/EU. This product is allowed to...

  • Page 7: Packing List

    1. Packing List Please unpack carefully and check that all items listed below are received. If any item is missing or damaged, please contact your dealer. Name Qty. Body Worn Camera Battery Belt Clip USB Cable Power Adapter Charger Documentation Kit Pictures listed in this manual are for reference only.

  • Page 8: Product Overview

    2. Product Overview 2.1 Product Layout 2.2 LCD Icons Icon Description WLAN is enabled with no connection established (applicable to Wi-Fi version only). WLAN is enabled and established with network connection (full signal); the grids indicate the signal strength, the more, the stronger (applicable to Wi-Fi version only).

  • Page 9: Led Indicators

    Icon Description : Low battery.  : Full battery.  Displays the current time. Video Recording mode. Photo taking mode. Audio recording mode. Pre- or post-event recording mode. Tagged Video. The video is damaged. The photo is damaged. The audio is damaged. 2.3 LED Indicators Status Description...

  • Page 10: Specifications

    Status Description recharge or replace the battery in time. Flashes orange slowly The product is recording an audio. Flashes red and blue in turn The product is pairing with other BT devices. Flashes blue rapidly BT connection is established. 2.4 Specifications Body Worn Camera (BWC) Dimensions (H×W×D) 26 mm×55 mm×85.5 mm...
  • Page 11 Screen Type TFT-LCD 262K color display Standard: 16 GB  TF Card Storage Optional: 32 GB/64 GB/128 GB  Video Format Video Encoding Format H.264 Video Resolution 480P (30 FPS), 720P (30/60 FPS), 1080P (30/60 FPS) Audio Format AAC (Advanced Audio Coding) Photo Format 4608×3456 (16-megapixel) ...
  • Page 12 Drop Resistance 2 m(with belt clip) ±6 kV (contact discharge)  ±12 kV (air discharge)  Operating Temperature 0 ˚ C to +60 ˚ C Storage Temperature –40 ˚ C to +85 ˚ C Compatible System Windows XP/Windows 7/Windows 8/Windows 10 Power Adapter Input AC 110 –...

  • Page 13: Before Use

    3. Before Use 3.1 Attaching the Battery Use only the Hytera standard or optional battery. Polarity reverse or use of other batteries  may result in explosion and fire hazards. The battery is applicable to a temperature range of 0 ˚ C to +55 ˚ C.

  • Page 14: Attaching The Belt Clip

    3.2 Attaching the Belt Clip Attach the belt clip according to the steps shown in the left figure. To remove the belt clip, do as the steps shown in the right figure.

  • Page 15: Charging The Product

    3.3 Charging the Product This product can be charged in two methods: charging through the USB cable or through the charger. 3.3.1 Charging through the USB Cable The LED indicator on the product tells its charging status, see 2.3 LED Indicators for details.
  • Page 16 3.3.2 Charging through the Charger Through the charger, you can charge the product attached with battery and a single battery simultaneously. The LED indicator on the product tells its charging status, see 2.3 LED Indicators for details; the LED indicator on the charger tells the charging status of the battery, as described in the following table. Status Description Flashes red and green in turn...

  • Page 18: Basic Operations

    4. Basic Operations 4.1 Turning On and Turning Off the Product Turning On the Product In power-off mode, press and hold the On/Off key for three seconds to turn on the product. Turning Off the Product In power-on mode, press and hold the On/Off key for three seconds to turn off the product . 4.2 Setting the Product You can set the BT, WLAN, WLAN hotspot, language, screen, volume, silent mode, night vision, anti-flicker, and other features.
  • Page 19 then press the Play/Pause/Confirm key. 4.2.2 WLAN This feature is applicable to Wi-Fi version only. You can enable or disable WLAN, view the network list, select the device to be connected, and view the IP address. After enabling WLAN, the product works in STA (Station) mode, and is able to connect to devices of AP (Access Point) mode.
  • Page 20 "12345678") of the product can be modified through the BWC Manager. Press the Left key or the Right key to select WLAN Hotspot, and then press the Play/Pause/Confirm key. Press the Play/Pause/Confirm key to enter the Hotspot On/Off screen. Press the Left key or the Right key to select ON or OFF, and then press the Play/Pause/Confirm key. (Optional) To view the Hotspot name, press the Left key or the Right key to select Name, and then press the Play/Pause/Confirm key.

  • Page 21: Screen Off

    4.2.5.2 Screen Off To set the time for the screen saver, do as follows: Press the Left key or the Right key to select Screen, and then press the Play/Pause/Confirm key. Press the Left key or the Right key to select Screen Off, and then press the Play/Pause/Confirm key. Press the Left key or the Right key to select 10s, 20s, 30s or OFF, and then press the Play/Pause/Confirm key.

  • Page 22: Silent Mode

    4.2.7 Silent Mode With this feature enabled, the product gives no alert tones, the indicator will not light up, and the display brightness is at the lowest level. To enable or disable the Silent Mode , do as follows: Press the Left key or the Right key to select Silent Mode, and then press the Play/Pause/Confirm key.

  • Page 23: Turning The Screen On Or Off

    4.3 Waking Up the Product from the Sleep Mode To wake up the product from sleep mode, press the Power On/Off key. 4.4 Turning the Screen On or Off To turn the screen on, press any key except the PTT key; to turn the screen off, press the Power On/Off key.

  • Page 24: Recording Audios

    In pre-event recording mode, the product loops to record video every 10 or 20 seconds according to the pre-recording time. Post-event Recording During video recording, press the Video Recording key to enter post-event recording. In post-event recording mode, the product records video for another 10, 20 or 30 seconds according to the post-recording time.

  • Page 25: Sending An Emergency Alarm

    4.12 Playing Back Audio or Video Recordings The video playback is similar to the audio playback. The following example shows how to play back the video. To play back videos, do as follows: In the Live View mode, press the Menu/Back key. Press the Left key or the Right key to select Video.
  • Page 26 The method to send and cancel an emergency alarm can be set by your dealer.  The emergency alarm has the highest priority. You can send an emergency alarm no matter the portable radio is transmitting or receiving. Sending an alarm In case of emergencies, press the Emergency key to make an emergency alarm, and start recording video and tag the video as critical evidence as described in the following situations.

  • Page 27: Troubleshooting

    5. Troubleshooting Phenomena Analysis Solution The battery may be improperly Remove the battery and attach it attached. again. The battery may run out. Recharge or replace the battery. The product cannot be The battery and the charging turned on . probes are in poor contact due to Clean the battery contacts.
  • Page 28 Phenomena Analysis Solution The product cannot The pre-event or post-event Enable the feature through the BWC pre-record or recording feature is not enabled. Manager. post-record the video . The product gives no alert tone; the indicator The Silent Mode is enabled. Disable the Silent Mode.

  • Page 29: Care And Cleaning

    6. Care and Cleaning To guarantee optimum performance as well as a long service life of the product, please follow the tips below. Product Care Do not pierce or scrape the product.  Keep the product away from substances that can corrode the circuitry. ...

  • Page 30: Optional Accessories

    7. Optional Accessories Use the accessories specified by the Company only; otherwise, we shall not be liable for any losses or damages arising out of the use of any unauthorized accessories. Contact your local dealer for the optional accessories of the product.
