Hytera ACCESSNET-T IP DIB-R5 advanced Operation Manual page 22

Product description
Legend: DIB-R5 advanced (front view)
No. Component
1 RX FILTER
2 DUPLEXER
3 Cable routing for Rx and GNSS cable
(Global Navigation Satellite System,
GNSS)
4 TETRA Channel Unit (CHU)
5 Base Station Controller Unit (BSCU)
6 Cable routing for Tx cable
7 Fan unit
8 Air entry for fan unit
9 Power Supply Unit (PSU) including
Power Supply Module (PSM)
Dummy plate for V
10 Cavity combiner
11 Levelling feet
12 Transport rollers
The following figure shows the top view of the DIB-R5 advanced. The following table
describes the components in greater detail.
22
voltage supply
DC
Number Described in
Ä Chapter 3.2.4.1 "RX FILTER"
1 to 3
on page 38
Ä Chapter 3.2.5.1 "DUPLEXER"
1
on page 40
1 ---
1 to 4 Ä Chapter 3.2.6 "TETRA Channel Unit
(CHU)" on page 42
1 to 2 Ä Chapter 3.2.7 "Base Station Controller
Unit (BSCU)" on page 44
1 ---
Ä Chapter 3.2.9 "Fan unit" on page 50
1
1 ---
Ä Chapter 3.2.2.2 "Power Supply Unit
1 to 4
(PSU) including Power Supply Module
(PSM)" on page 33
Ä Chapter 3.2.10 "Cavity combiner"
1
on page 51
4 ---
4 ---
Operation Manual 90DIBR5advancedOM02 - 1.0
DIB-R5 advanced
