The following figure shows the rear view of the DIB-R5 advanced with opened equipment
rack door. The following table describes the components in greater detail.
24
Component
Connection panel
GNSS splitter
TX/RXC
RXC ‒ optional
RXB
RXA
Front equipment rack door
Number
Described in
Ä Chapter 3.2.1.2 "Connec-
1
tion panel" on page 29
Ä Chapter 3.2.1.3 "GNSS
1
splitter" on page 31
1
---
1
---
1
---
1
---
1
---
