Assembly Kit - Danfoss VLT OneGearDrive Instruction Manual

Installation
2 2

2.5 Assembly Kit

6 1
Figure 2.1 Assembly Kit
1 Shaft
2 Disc
3 Retaining ring
4 Lock washer
5 Fixing screw (filister head)
6 Key
Table 2.1 Legend to Figure 2.1
Type
OGD-30
OGD-35
OGD-40
Table 2.2 Dimensions
1) Key length required for b
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
Mounting Instructions
Rotate the disc (2) and fit it against the retaining ring (3). Both items are included in every delivery.
The fixing screw (5) and lock washer (4) are not included in the delivery. The parts are dependent on the length and size of
the shaft. For further information, refer to the mounting arrangement, see 2.4 Mounting Arrangement.
2-2
3 2 4
Holding
Retaining ring (3) Lock washer (4)
DIN 472 DIN 7980
1.18 x 0.05 [30 x 1.2] 0.39 [10]
1.38 x 0.06 [35 x 1.5] 0.47 [12]
1.58 x 0.07 [40 x 1.75] 0.63 [16]
in Table 2.3. Adapt the key length according to the shaft length used (b) in Table 2.3.
min
MG75C322 - VLT
®
VLT OneGearDrive Instruction Manual
5
Dimensions (in [mm])
Fixing screw (5)
DIN 912-8.8
M 0.39 x 1.18 [10x30]
M 0.47 x1.38 [12 x 35]
0.63 x 1.38 [M16 x 35]
®
is a registered Danfoss trademark
Key (6)
DIN 6885
Width x Height x Length
A 0.32 x 0.28 x 3.94 [8 x 7 x 100]
1)
A 0.39 x 0.32 x 3.94 [10x8x100]
A 0.47 x0.32 x 3.94 [12 x 8 x 100]
1)
1)
